Feit Electric S13CWPK5CCTLSBZ Use And Care Manual

Outdoor commercial wall light
Hide thumbs

Advertisement

Quick Links

Download this manual
Model #S13CWPK5CCTLSBZ
USE AND CARE GUIDE
OUTDOOR COMMERCIAL WALL LIGHT
READ BEFORE INSTALLATION
SAVE THESE INSTRUCTIONS
Questions, problems, missing parts? Before returning to the store,
call Feit Electric Customer Service
8 a.m. - 5 p.m., PST, Monday - Friday
1-866-326-BULB (2852)
FEIT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Feit Electric through the purchase of this LED yard light fixture.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products
available for your home improvement needs. Thank you for choosing Feit Electric!
