Model #S13CWPK/MM/BZ
USE AND CARE GUIDE
OUTDOOR COMMERCIAL WALL LIGHT
READ BEFORE INSTALLATION
SAVE THESE INSTRUCTIONS
THANK YOU
We appreciate the trust and confidence you have placed in Feit Electric through the purchase of this LED yard light fixture. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Feit Electric!
Advertisement
Table of Contents
Related Manuals for Feit Electric S13CWPK/MM/BZ
Summary of Contents for Feit Electric S13CWPK/MM/BZ
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Feit Electric through the purchase of this LED yard light fixture. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
This product is warrantied to be free from defects in workmanship and materials for up to 5 years from date of purchase. If the product fails within the warranty period, please contact Feit Electric at info@feit.com, visit feit.com/contact-us or call 1-866-326-BULB (2852) for instructions on replacement or refund. REPLACEMENT OR REFUND IS YOUR SOLE REMEDY. EXCEPT TO THE EXTENT PROHIBITED BY... -
Page 3: Pre-Installation
Pre-Installation TOOLS REQUIRED (NOT INCLUDED) NOTE: Hardware not shown to actual size. Phillips Drill 1/4 in. Drill bit screwdriver HARDWARE INCLUDED Part Description Quantity Wall Light Front Cover Screws Wall Mounting Screws J-Box Mounting Screws Plastic Anchors Wire Connectors Sensor Cover... -
Page 4: Installation
0-10V dimmers only (purple +10V, pink -10V). Purple (+10V) - Purple from dimmer Pink (-10V) - Pink from dimmer. See wiring diagram B. FEIT ELECTRIC COMPANY I PICO RIVERA, CA | (800) 543-3348 | FAX (562) 908-6360 | www.feit.com... - Page 5 Wall Mount Installation (continued) Re-Attach the Front Cover Apply Sealent □ □ Re-attach the Front Once the fixture is tightly secured to the wall, apply Cover to the Back Plate silicone sealant around the base of the fixture to and re-connect the prevent moisture from reaching the connections.
- Page 6 □ Turn power back on at the wall switch, circuit breaker Pink (-10V) - Pink or fusebox. from dimmer. See wiring diagram B. FEIT ELECTRIC COMPANY I PICO RIVERA, CA | (800) 543-3348 | FAX (562) 908-6360 | www.feit.com...
-
Page 7: Wiring For A Standard Wall Switch
Wiring for a Standard Wall Switch WIRING DIAGRAM A Twist-on wire connector Supply Line (Black) Line (Black) Supply Neutral (White) DRIVER Neutral (White) Connector to LED (Green or Bare) J-Box Grounding (Green) Supply Grounding (Green/Yellow) Wiring for 0-10V Dimmer WIRING DIAGRAM B Twist-on wire connector Supply Line (Black) Line (Black) - Page 8 100% and will then drop to 30% after the warmup time. Brightness will go to 100% once motion is detected. Motion Motion Detection Detection Area Area 180º FEIT ELECTRIC COMPANY I PICO RIVERA, CA | (800) 543-3348 | FAX (562) 908-6360 | www.feit.com...
-
Page 9: Troubleshooting
Troubleshooting Problem Possible Cause Solution The power is off. Make sure the power supply is on. Check the wiring. Contact a qualified and The light will not There is a faulty wire licensed electrician if you are not comfortable illuminate. connection.
