INSTRUCTIONS–PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
Model 980
Non-Bleeder Style Turbine Spray Guns
50 psi (0.35 MPa, 3.5 bar) Maximum Inlet Fluid Pressure
100 psi (0.7 MPa, 7 bar) Maximum Inlet Air Pressure
Model 980S
Includes 1-quart (1 liter) cup
240090 Model 980S, without fluid set
240093 Model 980S, with # 3 fluid set
240094 Model 980S, with #4 fluid set
240095 Model 980S, with #5 fluid set
240098 Model 980S, with #3 fluid set , flat bottom cup
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
8066B
ECOPYRIGHT 1998, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
308810
Model 980P
240100 Model 980P, without fluid set
240103 Model 980P, with # 3 fluid set
Rev. F
8065A
