INSTRUCTIONS–PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
Series 960
Turbine Spray Guns
50 psi (0.35 MPa, 3.5 bar) Maximum Inlet Fluid Pressure
100 psi (0.7 MPa, 7 bar) Maximum Inlet Air Pressure
Model 960
Includes 1-quart (1-liter) cup
240080, without fluid set
240083, with #3 fluid set
240084, with #4 fluid set
240085, with #5 fluid set
243920, with 2.0 fluid set
GRACO INC. P.O. BOX 1441
Model 960P
240772, without fluid set
240773, with #3 fluid set
243592, with #1 fluid set
MINNEAPOLIS, MN 55440–1441
ECOPYRIGHT 1993, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
308336
First choice when
quality counts.t
Model 960GF.5
Includes 1/2-quart (1/2-liter) cup
240530, without fluid set
Model 960GF.75
Includes 3/4-quart (3/4-liter) cup
240532, without fluid set
Rev. J
05292A
