Page 1
SENSI SMART THERMOSTAT ™ Humidity control guide Models: 1F87U-42WF, ST55, NH-AWIFI, OH-AWIFI Emerson Electric Co. All rights reserved Version: April 2023 R-5622...
Page 2
Heat pump changeover (reversing or 3-wire hot water zone valve valve) connection (configure as connection. (configurable as O, B O or B in the installer menu) or 2 in the installer menu) no function “L” terminal connection Sensi smart thermostat | HUMIDITY GUIDE...
Page 3
NORMAL HIGH FURNACE/AIR HANDLER TERMINAL STRIP RELAY 90 293Q OR EQUIVALENT DEHUM SPEED FAN HEAT FAN OUTPUT COOL FAN OUTPUT 1. NORMAL COOL SPEED POSITION DHM ENERGIZED 2. DEHUM SPEED MODE DHM DE ENERGIZED Sensi smart thermostat | HUMIDITY GUIDE...
Page 4
Od – Optimal dehumidification dH AA Add accessory (overcool to dehumidify) Oc – Optimal comfort (wired dehumidification) Dehumidification dH SP Off/40% – 95% (5% increments) Set point Wireless radio Off/On Turns wi-fi radio on/off Sensi smart thermostat | HUMIDITY GUIDE...
Page 5
Look for the "dH AA" menu. Up Arrow Use the button to toggle Dehumidity "On." Press Next. Up Arrow Use the button to change the set percentage (SP) to your desired percentage to maintain. Press Exit. Sensi smart thermostat | HUMIDITY GUIDE...
Page 6
HUMIDIFICATION CONTROL IN THE SENSI APP Adjusting the humidity features from the Sensi app After initially turning the feature on in the thermostat menu, you can edit them from the Sensi app. Open the Sensi app. Thermostat Name. Tap your Settings Gear.
When can I get the firmware OTA OTA updates are pushed via Wi-Fi after being update for humidity control? registered to the customer's account on the Sensi app. Sensi Touch (1F95U) and Sensi (1F87U) smart Which versions of Sensi thermostats are thermostats are all backward compatible.
