Summary of Contents for Hauslane Chef WM-630SS-30
- Page 1 INSTRUCTION, USE & CARE MANUAL Models WM-630SS-30 | WM-630SS-36...
-
Page 2: Table Of Contents
Heat oils slowly on low or medium settings. Use this range hood only in the manner intended by the manufacturer. If you have the questions, contact HAUSLANE Always turn hood ON when cooking at high heat or at 1-800-929-0168 or email at info@hauslane.com. -
Page 3: Warranty Information
24"; any installation less than 24" may cause overheating and cause Please read product specification label on range hood damage to the range hood, HAUSLANE does not warrant for further information and requirements. this improper installation. -
Page 4: Specifications
Specifications Dimentions Volts Hertz Fan CFM Speeds Light Wattage Stainless Steel Grade 29.75” W 19.7” D 3W (LED) 22.2-41.3” H 10.8” 11” 19.5” 19.75” Max 42” 19.5” 3” 29.6” Tools Needed Before you begin the installation process, gather the following tools: Measuring Tape Pencil Flathead Screwdriver... -
Page 5: Package Contents
Package Contents Range Hood Chimney User Manual Aluminum Grease Filter Flexible Aluminum Duct Chimney Mounting Bracket Chimney Bracket Parts Included 6 x AA Hood mounting screws 6 x BB Drywall anchor 2 x CC Chimney mounting bracket screws 3 x DD Bottom chimney fix screws 4 x EE Glass fastening screws WM-630 USER MANUAL... -
Page 6: Preparation: What To Do Before Installation
Preparation: What to Do Before Installation Before installing your range hood, carefully follow these steps: 4. Check Your Power Supply and Ducts Check to ensure your main voltage is in line with the 1. Read This Manual required voltage outlined on the rating plate inside this Read through all the steps. -
Page 7: How To Install Your Range Hood
IMPORTANT: Power the range hood and test all functions before proceeding with the installation. If the range hood is not working properly, please contact us immediately (1-800-929-0168 / info@hauslane.com). 2. Measure and Mark the Installation Area Using your pencil, draw a vertical line on the supporting wall, directly in the center of the area where the hood will be installed. -
Page 8: Attacth Duck To Outer Adapter
For 10-foot ceiling or higher, we recommend using a on the damper assembly operate freely. chimney extension. They can be purchased separately on our website at www.hauslane.com. Note: Ductwork is not included with this range hood. 9. Complete Ductwork (For Ducted Mode) Decide where the ductwork (not included) will run between the hood and the outside. -
Page 9: Install Filter (For Non-Duckted Mode)
10. Install Charcoal Filter (for non-ducted mode) Be Careful with Electrical Connections. Install a charcoal filter (not included). The air will flow out from the two grids on the two sides of the chimney top. WARNING: Electrical wiring must be done by a qualified person(s) in accordance with all applicable codes and standards. -
Page 10: How To Use Your Range Hood
How to Use Your Range Hood Now that your range hood is installed, it’s time to learn how to use it. It is very simple to use and is operated entirely using the front control panel. 1- Light On/Off 2- Fan High 3- Fan Medium 4- Fan Low 5- Fan On/Off... -
Page 11: Basic Maintenance Instructions
Basic Maintenance Instructions Your range hood requires some easy routine maintenance to Replacing the LED Lamps keep it running efficiently. CAUTION: Always switch off the electrical supply Maintaining the Baffle Filter before replacing LED lamps. Clean the grease filters frequently—we suggest cleaning every 2 months, or more frequently for heavy use. -
Page 12: Troubleshooting Tips
3. If replacement and/or tightening does not solve, you may need to replace the lighting service system on the hood. Still experiencing problems after following these steps? Contact a technician to assist. Contact us at 1-800-929-0168 or info@hauslane.com. WM-630 USER MANUAL... -
Page 13: Contact Hauslane
Contact Hauslane Extended Warranties If you are interested in an extended warranty, sign up on our website at www.hauslane.com Parts and Accessories If you need replacement parts or accessories, visit www.hauslane.com Contact Us We’d be happy to answer your questions or resolve any issues you may have.
