1JC0P1P0001 - -
© 2012 Sanyo Manufacturing Corporation
Please read before operating your HDTV!
PROTECTING THE LCD
POSITIONING THE HDTV
• Always use a firm and flat surface when
positioning your HDTV.
CAUTION: The screen can be damaged if
it is not maintained properly.
• Do not position the unit in a confined
• Do not use hard objects such as hard
cloth or paper to clean the screen.
• Allow adequate space for proper venti-
• Do not use excessive pressure when
cleaning the screen; excessive pressure
• Do not position the HDTV where it is
can cause permanent discoloration or
easily reachable by small children and
may present risk of injury.
• NEVER spray liquids on the screen.
• Once HDTV is positioned, remove the
protective film covering front cabinet.
The American Academy of Pediatrics dis-
• Handle by the cabinet only.
courages media use by children younger
than two years. For more information,
• Handling by two or more people is rec-
• Never touch the screen when handling.
ENERGY STAR is a set of power-saving guidelines issued by the U.S. Environmental Protection
• Handling damage is not covered under
Agency (EPA). ENERGY STAR is a joint program of the U.S. Environmental Protection Agency
and the U.S. Department of Energy helping us all save money and protect the environment
through energy efficient products and practices.
• Do not remove the protective film
covering the front cabinet while
Changes to default as-shipped television configuration and settings or enabling certain optional
handling the HDTV.
features and functionalities will change the energy consumption of the television, this may
increase energy consumption beyond the limits required for ENERGY STAR qualification.
Install two (2) "AAA" batteries in the
NOTE: Skip these steps if you are wall
remote control. (Not included)
mounting the TV.
Place HDTV face down on a
• Replace both batteries at the same
padded or cushioned flat surface
time. Do not use a new battery with a
to protect the screen and finish.
Carefully insert the stand base to
• There's a risk of explosion if a battery
the bottom of the HDTV and secure
is replaced by an incorrect type.
it by inserting four (4) screws as
• Keep away from moisture.
indicated in the diagram below.
• Be sure to match the "+" and "–"
NOTE: Stand base screws are located
signs on the batteries with marks
in the literature package.
inside the remote control.
• Please properly dispose of used up
WARNING: The batteries (or battery
pack) shall not be exposed to excessive
heat such as sunshine, fire or the like.
ANTENNA CONNECTION FOR
OFF-AIR SIGNALS OR CABLE
Position the HDTV on a firm and
Hook up your antenna or your cable
flat surface with adequate space
service to the HDTV's ANT terminal
for proper ventilation.
with the use of a 75 OHM coaxial cable.
NOTE: Keep your indoor antenna at
Wall mounting of the HDTV must be
performed by a skilled person.
If stand base disassembly is required:
Place HDTV face down on a
padded or cushioned flat surface
to protect the screen and finish.
Remove the four (4) screws secur-
ing the foot stand. CAUTION: Hold
the stand firmly as you remove
the last screw.
Use the four (4) screws included in the
literature package to secure the HDTV
to a wall mounting kit.
The tuner in this HDTV can receive:
NOTE: Wall mounting kit is not included.
Digital and Analog off air signals
VESA standard interface: 200 x 200
from an antenna
Mounting screws measurements:
Analog or ClearQAM cable channels
M6 (6mm) Diameter, Length—12mm
from a direct Cable TV connection.
Manufactured under license from Dolby
Laboratories. "Dolby" is a trademark of
HDMI, the HDMI Logo and High-Definition
Multimedia Interface are trademarks or regis-
tered trademarks of HDMI Licensing LLC in
the United States and other countries.
As an Energy Star
Sanyo Manufacturing Corporation
has determined that this product
meets the Energy Star
lines for energy efficiency.
Manufactured under license from Audyssey
Laboratories. U.S. and foreign patents pending.
Audyssey Dynamic Volume
trademark of Audyssey Laboratories.
Source: AC 120V, 60Hz
AC Power Consumption: 95 watts
Weight: 20 lbs (w/stand)
NOTE: Dimensions are in inches
LAMPS, DISPOSE OF
SANYO television customers
Recycling at 888-769-0149 or
w w w . m r m r e c y c l i n g . c o m
regarding SANYO's waste
INITIAL CHANNEL SEARCH
Before proceeding, please make
sure to correctly hook up your
antenna or cable connection and
all AV equipment to your HDTV.
1. PLUG IN AC POWER CORD
120V AC, 60Hz
2. TURN ON TV
3. TV SET LOCATION SELECTION:
Select "Home Mode" to set the
HDTV's backlight to an Energy Star
qualified level, or select "Store
Mode" to set the backlight to a retail
4. CHANNEL AND SIGNAL SEARCH:
Select "Signal Search" and press
ENTER to perform a channel search
from an Antenna or a direct Cable
connection, and a signal search
from devices hooked up to the
HDTV's AV input jacks.
5. SIGNAL SEARCH RESULT SCREEN
The final setup screen displays ana-
log and digital channels found, as
well as AV inputs detected.
Select Finish Setup and press
least 3 ft. away from the televi-
sion set and any other electron-
NOTE: If you wish to repeat the
process, select Repeat.
Channel Search Result: Succesfully Completed
ANALOG / DIGITAL
If you are having problems, call us toll-free at 1-800-877-5032
AV INPUT SELECTION
Press the INPUT key to select the
correct AV input for the video source
you wish to watch.
NOTE: Unused AV inputs may be dis-
abled with the Input Setting feature.
CAUTION: TO REDUCE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding-type plug has two blades and a third
is a registered
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit fully into your out-
let, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched par-
ticularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate nor-
mally, or has been dropped.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gen-
erates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harm-
ful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
CAUTION: FCC Regulations state that improper modifications or unauthorized changes to this unit may void the user's authority to
operate the unit.
This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require
a safety connection to electrical earth.
HDTV INPUT/OUTPUT REFERENCE ________________________________________
HDMI (INPUT1 or INPUT2)
Use HDMI INPUT1 & 2 to hookup HD digital devices such as
a Blu-ray player, HD Cable Box, HD Satellite Receiver or
Connect your digital device's HDMI output to any of the two
(2) HDMI inputs on your HDTV with the use of an HDMI
NOTE: A DVI connection is possible via the HDMI (DVI) INPUT1
using an appropriate cable or adapter and connecting the
audio to the Stereo Mini AUDIO jack.
jack is used to connect a USB mass storage
device to watch digital images stored in JPEG format.
AUDIO mini stereo jack (3.5mm)
For AUDIO signal from DVI device.
Digital Audio Output (Coaxial)
Hookup a multichannel receiver with the use of a phono-
type digital audio cable.
Analog / Digital Antenna Input
Hook up your indoor or outdoor digital antenna, or a direct
Cable service (Analog or ClearQAM).
Green (Y), blue (Pb), and red (Pr) Video inputs plus the
white and red Audio inputs.
COMPONENT connection will accept SDTV, EDTV and
HDTV video signals. Use it for great image quality from di-
gital devices such as a DVD player or Video Game system.
Match your digital device's Component output jacks to the
Component input jack set (VIDEO2) on your HDTV.
NOTE: A composite connection is possible via VIDEO INPUT2
using the Y (VIDEO) jack and the L/R audio jacks (see
Composite yellow (Video), plus white and red (Audio) input
COMPOSITE connections are used to hookup your analog
equipment such as a VCR or an older DVD player.
NOTE: Match the color of your device's output jack, the con-
nector and the HDTV's input jack.
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK
RISK OF ELECTRIC SHOCK DO NOT OPEN!
OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTE-
NANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THIS UNIT.
15. If an outside antenna is connected to the television equipment,
be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges.
In the U.S. Selection 810-21 of the National Electrical Code pro-
vides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location
of antenna discharge unit, connection to grounding electrodes,
and requirements for the grounding electrodes.
16. An outside antenna system should not be located in the vicini-
ty of overhead power lines or other electrical light or power
circuits, or where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or cir-
cuits as contact with them might be fatal.
EXAMPLE OF ANTENNA GROUNDING ACCORDING
TO NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
"Note to CATV system installer:
This reminder is provided to call the CATV system installer's
attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the build-
ing, as close to the point of cable entry as practical."
17. Wall or Ceiling Mounting—The product should be mounted to
a wall or ceiling only as recommended by the manufacturer.
18. Apparatus shall not be exposed to dripping or splashing, and no
objects filled with liquids, such as vases, shall be placed on it.
19. When the MAINS plug is used as the disconnect device, the
disconnect device shall remain readily operable.
HDTV SIDE PANEL
HDTV BACK PANEL
Sanyo Manufacturing Corp. 3333
Sanyo Road, Forrest City, AR 72335
Printed in Mexico, February 2012
US2P / 32-Z6TE / GXBM
