Alto-Shaam HALO HEAT EU2SYS-48 Specification Sheet

750-
HEATED DISPLAY CASE
The display case is constructed of 18 gauge, non-magnetic stainless steel. A tempered glass front encloses the display
case and can be lifted to a 90 degree angle for easy cleaning. Removable, sliding glass doors on the operator side are
included. Sliding door tracks have a "clean sweep" cutout allowing for easy cleaning and crumb removal. Framed end
glass with rubber gasket material protects glass edges from chipping and breakage. Two (2) 125V plug outlets are
included on 120/208-240V units only.
EU2SYS-48 - 48" (1219mm) length, with BU2 base,
EU2SYS-48/P - 48" (1219mm) length, with BU2 base, 47-5/16" (1202mm) self-service opening across full length of case front
EU2SYS-72 - 72" (1829mm) length, with BU2 base
EU2SYS-72/P - 72" (1829mm) length, with BU2 base, 71-5/16" (1811mm) self-service opening across full length of case front
EU2SYS-72/PL - 72" (1829mm) length, with BU2 base, 23-3/4" (603mm) self-service opening on left side of case front
EU2SYS-72/PR - 72" (1829mm) length, with BU2 base, 23-3/4" (603mm) self-service opening on right side of case front
EU2SYS-96 - 96" (2438mm) length, with BU2 base
EU2SYS-96/PL - 96" (2438mm) length, with BU2 base, 23-3/4" (603mm) self-service opening on left side of case front
EU2SYS-96/PR - 96" (2438mm) length, with BU2 base, 23-3/4" (603mm) self-service opening on right side of case front
®
. . .
P R I N T E D I N U S A
EU2SYS-48
FRONT VIEW
EU2SYS-48
BACK VIEW SHOWN WITH
-
TH II COOK AND HOLD OVEN
ADDITIONAL FEATURES & OPTIONS
The system base is not sold as a separate item. Order the full EU2SYS model to
receive the base.
Decorator panels are available as standard in painted black. When ordering, indicate
choice of panel colors. Custom colors are available on a factory quote basis.
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
: 262.251.3800 800.558.8744
PHONE
D U E T O O N G O I N G P R O D U C T D E V E L O P M E N T
EU2SYS
HALO HEAT ... a controlled, uniform heat source that gently
holds and surrounds food for better appearance, taste, and longer
holding life.
Holds and displays hot food fresh and moist for hours —
without adding water.
Expandable system to meet your specific requirements.
HOT DISPLAY CASE
— Curved glass styling.
— Displays hot food without condensation on glass.
— Thermostatically controlled heat source radiates from the base
of the display case in multiple heat zones.
— Overhead light zones with shatterproof coated bulbs.
— Holds a full range of standard (gastronorm) pan sizes, full-size
or half-size sheet pans.
— Standard stainless steel front and black painted end panels.
— Tempered sliding glass doors reflect heat back into the products
and mirror the display to enhance merchandising effect.
DECORATOR BASE
— Designed to accommodate your choice of low temperature
cook/hold oven, holding oven or 2-drawer holding cabinet.
— Stainless steel, distinctively framed in black as standard, and
brushed stainless or custom color as alternate choices.
. . ./
U S A CANADA
: www.alto-shaam.com
WEBSITE
,
S P E C I F I C AT I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E
. _______________________
ITEM NO
SERIES
HEATED DISPLAY SYSTEMS
: 262.251.7067 800.329.8744
FAX
.
. . .
U S A ONLY
# 6 9 - 1 0 / 0 6
