Adel CBI123A Instruction Manual

A D E L s y
A D E L s y
CBI123A – CBI123A/S – CBI123ARJ
Thank you for having chosen one of our products for your work. We are certain that it will give the utmost satisfaction and be a notable

General Description:

OUTPUT N°1
Battery module
OUTPUT N°2
Load Vdc Output
Charging Level
Auxiliary
Output
(CBIXXX/ARJ)
Vac Input

Application

CBI battery charger is a range of microprocessor-power supplies witch correctly charge sealed lead-acid batteries at all time
maximizing performance and life span.
Charge the battery in multi-stage principle, Fast and Trickle and automatically the device, check the battery efficiency in a lifetime to
prevent any risk of damage to the battery and allow leaving the charger permanently connected. Before begin the operations of
installation consult the manual.

Mains Characteristic

•
Nominal Input Voltage: 115 - 230 Vac
•
OUTPUT 1: for connection to Battery
•
OUTPUT 2: for connection to Load
•
Fast and trickle battery charge In according to DIN 41773
•
Signaling: replace battery, low battery, mains or buffering
•
Overload and short circuit protections
•
Safety isolation in according with EN 60950
•
Output 12 Vdc 6 A 50° C also without mains
•
Degree of protection IP20
•
Rail DIN mounting
Instruction Manual
ADEL system srl Via L. Barchi 9/B, 42100 Reggio Emilia (Italy) – Tel. ++39-0522-345518
Fax. ++39-0522-345551 – Internet: www.adelsystem.com – e-mail: info@adelsystem.it
s t e m
s t e m
Intelligent Battery Charger
help on the job.
Mains or
Backup
Low Battery or
Battery replacement
Monitor Led
Battery Type
Configuration Jumper
CBI123A_R8 Eng.doc
