Summary of Contents for Synology DX1222
- Page 1 Expansion Unit DX1222 Hardware Installation Guide...
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Before You Start Package Contents Synology DX1222 at a Glance Other LED Indicators Hardware Specification Spare Parts Safety Instructions Chapter 2: Hardware Setup Tools and Parts for Component Installation Install Drives Connect with Synology NAS... -
Page 3: Chapter 1: Before You Start
Chapter Before You Start Thank you for purchasing this Synology product! Before setting up your new Synology NAS, please check the package contents to verify that you have received the items below. Also, make sure to read the safety instructions carefully to avoid harming yourself or damaging your Synology NAS. -
Page 4: Synology Dx1222 At A Glance
"LED Indicator Table". 1. Press to power on your Synology NAS. POWER Button 2. To power off your Synology NAS, press and hold until you hear a beep sound and the Power LED starts blinking. Front Displays the status of the Synology NAS connection. For LINK Indicator more information, see "LED Indicator Table". -
Page 5: Other Led Indicators
Synology NAS disconnected Note: 1 Please try to restart your Synology NAS or re-insert the drives, then run the HDD/SSD manufacturer's diagnostic tool to check the health status of the drives. If you can sign in to DSM, please run the built-in S.M.A.R.T. -
Page 6: Hardware Specification
Hardware Specification Item DX1222 Compatible Drive Type 3.5"/2.5" SATA x 12 Size (H x W x D) (mm) 270 x 300 x 340 Weight (kg) 9.02 • FCC Class B • CE Class B • UKCA • BSMI Class B Agency Certification •... -
Page 7: Spare Parts
Spare Parts www.synology.com/products/spare_parts Visit if you need to replace system fans, disk trays, or power supply units. Model Name Picture Description Disk Tray (Type D6) 3.5"/2.5" Drive Tray With Lock FAN 120*25_6 System Fan 120*120*25 mm x 2 PSU 550W_1... -
Page 8: Safety Instructions
Safety Instructions Keep away from direct sunlight and away from chemicals. Ensure a stable environment with no abrupt changes in temperature or humidity. Place the unit right side up at all times. Keep the unit away from liquids. Before cleaning, unplug the power cord. Do not use chemical or aerosol cleaners. Wipe with damp paper towels. -
Page 9: Chapter 2: Hardware Setup
Tools and Parts for Component Installation Please prepare the following tools and parts before setting up your expansion unit: • A screwdriver (only for 2.5" drives) www.synology.com/compatibility • At least one 3.5" or 2.5" SATA drive (please visit for compatible drive... - Page 10 3 Load drives in the drive trays. • For 3.5" drives: Remove the fastening panels from the sides of the drive tray. Place the drive in the drive tray. Then insert the fastening panels to secure the drive in place. •...
- Page 11 5 Press the handle back into the front panel until you hear a click to secure the hard drive tray in place. 6 Insert the hard drive tray key into the hard drive tray lock, turn the key clockwise (to the "I" position) to lock the hard drive tray handle, and then remove the key.
-
Page 12: Connect With Synology Nas
1 Connect one end of the power cord to the power port of the expansion unit, and the other to the power outlet. 2 Connect the expansion cable to the expansion ports of DX1222 and Synology NAS. After the connection is complete, DX1222 will be turned on or off automatically when the connected NAS powers on or off. -
Page 13: Chapter 3: System Maintenance
System Maintenance Replace System Fan If the cooling fan located on the back of the Synology NAS malfunctions, please follow the steps below to remove the malfunctioning fan and replace it with a new one. 1 Power off your Synology NAS and remove the power cord. - Page 14 Make sure that all 6 push pins on the new module are pulled outwards before the module is placed into your Synology NAS, and then press the push pins back into place to secure the fan module. 14 Chapter 3: System Maintenance...
-
Page 15: Confirm Connection And Manage Storage Spaces
Confirm Connection and Manage Storage Spaces 1 Log in to the DiskStation Manager (DSM) of the main NAS unit. 2 Go to Control Panel > External Devices > External Devices to confirm the expansion unit is successfully connected. 3 Go to Storage Manager to manage storage space creation or expansion. •... - Page 16 The data cannot be stored on the expansion unit if an independent volume has been created on it. • Drives previously used in a Synology NAS are not readable when directly inserting them into this expansion unit, and vise versa.
- Page 17 Section 5. License Limitations. The license set forth in Sections 1, 2 and 3 applies only to the extent that you have ordered and paid for the Product and states the entirety of your rights with respect to the Software. Synology reserves all rights not expressly granted to you in this EULA.
- Page 18 Arbitration Law and related enforcement rules of the country in which Synology Inc. was organized. In such cases, the arbitration will be limited solely to the dispute between you and Synology. The arbitration, or any portion of it, will not be consolidated with any other arbitration and will not be conducted on a class-wide or class action basis.
- Page 19 Section 3. Limited Warranty and Remedies 3.1 Limited Warranty. Subject to Section 3.2, Synology warrants to the Customer that each Product (a) will be free of material defects in workmanship and (b) under normal use will perform substantially in accordance with Synology's published specifications for the Product during the Warranty Period.
- Page 20 Section 4. Limitations of Liability 4.1 Force Majeure. Synology will not be liable for, or be considered to be in breach of or default under this Warranty on account of, any delay or failure to perform as required by this Warranty as a result of any cause or condition beyond its reasonable control (including, without limitation, any act or failure to act by Customer).
- Page 21 Arbitration Association, except as otherwise provided below. The arbitration will be conducted before a single arbitrator, and will be limited solely to the dispute between Customer and Synology. The arbitration, or any portion of it, will not be consolidated with any other arbitration and will not be conducted on a class-wide or class action basis. The arbitration shall be held in King County, Washington, U.S.A.
- Page 22 5.9 Entire Agreement. This Warranty constitutes the entire agreement, and supersedes any and all prior agreements, between Synology and Customer related to the subject matter hereof. No amendment, modification or waiver of any of the provisions of this Warranty will be valid unless set forth in a written instrument signed by the party to be bound thereby.
- Page 23 FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 24 この装置は、クラス B 機器です。この装置は、住宅環境で使用することを 目的 としていますが、この装置がラジオやテレビジョン受信機に近接して使 用され ると、受信障害を引き起こすことがあります。 取扱説明書に従って正しい取り扱いをして下さい。 VCCI 一 B...
