- Page 1 User Manual VLHDBSP1X4V2 1x4 HDBaseT Splitter All Rights Reserved Version: VLHDBSP1X4V2_2022V1.0...
- Page 2 1x4 HDBaseT Splitter Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 1x4 HDBaseT Splitter SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
- Page 4 1x4 HDBaseT Splitter Elektro- und Elektronikgeräte Informationen für private Haushalte Das Elektro- und Elektronikgerätegesetz (ElektroG) enthält eine Vielzahl von Anforderungen an den Umgang mit Elektro- und Elektronikgeräten. Die wichtigsten sind hier zusammengestellt. 1. Getrennte Erfassung von Altgeräten Elektro- und Elektronikgeräte, die zu Abfall geworden sind, werden als Altgeräte bezeichnet.
- Page 5 1x4 HDBaseT Splitter bei rü cknahmepflichtigen Vertreibern unter anderem dann, wenn ein neues gleichartiges Gerät, das im Wesentlichen die gleichen Funktionen erfü llt, an einen Endnutzer abgegeben wird. Wenn ein neues Gerät an einen privaten Haushalt ausgeliefert wird, kann das gleichartige Altgerät auch dort zur unentgeltlichen Abholung übergeben werden;...
-
Page 6: Table Of Contents
1x4 HDBaseT Splitter Table of Contents 1. Product Introduction ....................7 1.1 Features ......................7 1.2 Package List ...................... 7 2. Technical Specification ....................8 2.1 HDBaseT Splitter ....................8 2.2 Video Resolution Down-scaling ............... 10 3. Panel Description ...................... 11 3.1 Splitter Front Panel .................. -
Page 7: Product Introduction
Support 24V PoC, the HDBaseT receiver can be powered by HDBaseT splitter. ⚫ 1.2 Package List 1x RS232 Cable (3-pin to 3-pin, used ⚫ ⚫ 1x VLHDBSP1X4V2 1x4 HDBaseT Splitter for RS232 cascade) 2x Mounting Ears with 4 Screws ⚫ 1x RS232 Cable (3-pin to DB9) ⚫... -
Page 8: Technical Specification
1x4 HDBaseT Splitter 2. Technical Specification 2.1 HDBaseT Splitter Video Input Input (1) HDMI Input Connector (1) Female type A HDMI HDMI Input Resolution Up to 4K@60Hz 4:4:4 8bit Video Output Output (1) HDMI, (4) HDBT Output Connector (1) Female type A HDMI; (4) RJ45 HDMI Output Resolution Up to 4K@60Hz 4:4:4 HDBT Output Resolution... - Page 9 1x4 HDBaseT Splitter (1) EDID, (1) FIRMWARE, (1) ID PRESET, (1) IR ALL IN/LOOP IN, Control port (1) IR OUT, (4) IR IN, (1) IR LOOP OUT, (1) RS232 IN, (1) RS232 OUT, (1) 4-pin DIP switch, (1) Micro-USB, (1) DIP switch, (7) 3.5mm mini Control Connector jacks, (2) 3-pin terminal blocks General...
-
Page 10: Video Resolution Down-Scaling
1x4 HDBaseT Splitter 2.2 Video Resolution Down-scaling The product supports video resolution down-scaling, the 4K input can be automatically degraded to 1080p output for compatibility with 1080p display, shown in the below chart. HDMI Output: Input Output Resolution Refresh Color Space Downscale 1080p Specs 3840x2160... -
Page 11: Panel Description
1x4 HDBaseT Splitter 3. Panel Description 3.1 Splitter Front Panel INPUT OUTPUTS 1 2 3 4 HDMI HDBT 1 HDBT 2 HDBT 3 HDBT 4 FIRMWARE 1. POWER LED: Illuminates red when power is applied. 2. INPUT LED: Illuminates green when there is HDMI source input. 3. - Page 12 1x4 HDBaseT Splitter 4. CONTROL: IR ALL IN/LOOP IN: Connects to IR receiver to control far-end display device, ⚫ or it can be connected to IR LOOP OUT of previous splitter. IR OUT: Connects to IR emitter to control the local source device by IR. ⚫...
-
Page 13: System Connection
1x4 HDBaseT Splitter 4. System Connection Speaker Receiver 4K TV IR Emtter Laptop Receiver Remote IR Receiver Blu-Ray Receiver ID = 1 Receiver HDMI: Audio: RS232: HDBaseT: ID = 2 Next 1x4 Splitter... - Page 14 1x4 HDBaseT Splitter Cascade Connection: The splitter supports cascade connection to distribute video signal to multiple video displays. Use the following connection diagram as a guide for cascading multiple units. Note that each unit must have a unique ID if using RS232 control. Laptop Receiver Remote...
-
Page 15: Ir Control
1x4 HDBaseT Splitter 5. IR Control The IR receivers and emitters can be connected to the system to allow for IR control of remote devices. The bidirectional IR feature provides the two-way control either for the source or display device(s). Use the following sample connection diagrams to connect for IR remote control. -
Page 16: Controlling The Display Device By Ir All In
1x4 HDBaseT Splitter 5.2 Controlling the Display Device by IR ALL IN The IR ALL IN port of the splitter can receive all IR signals from remotes to send to control displays. Connect an IR receiver to IR ALL IN port of the splitter, and then connect four IR emitters to IR OUT port on HDBaseT receivers. -
Page 17: Controlling The Source Device
1x4 HDBaseT Splitter 5.3 Controlling the Source Device The IR OUT port of the splitter can send all IR signals to control source device. Connect four IR receivers to IR IN ports on HDBaseT receivers, and then connect an IR emitter to IR OUT port of the splitter. HDMI: HDBT: IR IN... -
Page 18: Rs232 Control
1x4 HDBaseT Splitter 6. RS232 Control The splitter and compatible receivers features RS232 ports to transmit RS232 signals from computer to control far-end third-party devices by using 3-pin to DB9 cable and a RS232 control software, such as docklight. After installing the RS232 control software, please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly. - Page 19 1x4 HDBaseT Splitter Command Example and Command Function Feedback param1=0~15. The splitter ID 0~9, A~F. @ID:5 param1=ALL. All splitters. @5_V1.x.x @5_RS232_BAUD xxx @5_HDBT_PoC_x_ON/OF @5_SPDIF_ON/OFF @5_I2S_ON/OFF @5_EDID:xxx @5_HDCP:xxx #5_GET_DIP Get EDID DIP switch status. #param1_GET_DIP param1=0~15. The splitter ID 0~9, A~F. @5_EDID:xxx param1=ALL.
- Page 20 1x4 HDBaseT Splitter The following commands do not require end mark. Command Example and Command Function Feedback Send ASCII command to control the far-end #5_SET_A_1_0:ABC12345 third-party device which is connected to the RS232 port of HDBaseT receiver. param1=0~15. The splitter ID 0~9, A~F. param1=ALL.
-
Page 21: Dip Switch Operation
1x4 HDBaseT Splitter 7. DIP Switch Operation 7.1 EDID Management The DIP switch on the front panel can be used to set the EDID to a fixed value to ensure the compatibility in video resolution. The switch represents “0” when in the lower (OFF) position, and it represents “1” while putting the switch in the upper (ON) position. -
Page 22: Hdcp Mode
1x4 HDBaseT Splitter 7.2 HDCP Mode Put switch 4 on “ON” position to select HDCP Active mode, or to “OFF” for HDCP Passive mode. Switch Status Mode HDCP Passive Automatically follows the HDCP version of source OFF (0) (Default) device. ⚫...
