- Page 1 User Manual CH0102 1x1 HDMI Signal Manager...
-
Page 2: Fcc Statement
1x1 HDMI Signal Manager Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till May 2016. -
Page 3: Safety Precautions
1x1 HDMI Signal Manager SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ... - Page 4 1x1 HDMI Signal Manager 1. Introduction 1x1 HDMI Signal Manager is a 1x1 HDMI signal manager supports HDMI2.0&HDCP2.2. It is designed to enhance the compatibility between HDMI source and display. The high-definition HDMI signal can be transmitted from HDMI source to match all kinds of display device.
-
Page 5: System Connection
1x1 HDMI Signal Manager 2. Appearances Name Description ① Power Indicator Illuminate red when powered on ② Connect with HDMI/ DVI source ③ DC 5V Micro USB power port, insert DC 5V 1A power adapter ④ Connect with HDMI/ DVI display ... -
Page 6: Specification
1x1 HDMI Signal Manager 4. Specification Input Output Input 1 HDMI IN Output 1 HDMI OUT 19-pin type-A female 19-pin type-A female Connector Connector HDMI HDMI Audio HDMI embedded HDMI embedded audio Audio audio General Transmission 4K*2K@60Hz≤15m Distance 1080P≤20m Bandwidth 18 Gbps Support PCM（2.0,2.1,5.1,6.1,7.1，... -
Page 7: Panel Drawing
1x1 HDMI Signal Manager 5. Panel Drawing 45.50 mm 12.00 mm 15.00 mm 6. Troubleshooting & Maintenance Problems Causes Solutions Color losing or vague/ Poor quality of the optical Change for qualified HDMI double image in HDMI fiber cable cable. display Not been powered Power up the unit... -
Page 8: After Sales Service
1x1 HDMI Signal Manager 7. After-sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. 4) Product Limited Warranty: We warrants that our products will be free from defects in materials and workmanship for three years, which starts from the first day the product leaves warehouse (check the SN mark on the product).
