Summary of Contents for VivoLink VL120015
- Page 1 User Manual VL120015 1x1 HDMI Convertor...
-
Page 2: Fcc Statement
This manual is only for operation instruction only, not for any maintenance usage. Trademarks Product model, VivoLink and its logo are trademarks of EET Europarts A/S. Any other trademarks mentioned in this manual are acknowledged as the properties of the trademark owner. -
Page 3: Safety Precautions
1x1 HDMI Convertor SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ... - Page 4 HDCP2.2 compliant signal to HDCP1.4 standarded signal. The EDID bypass function ensures the best resolution. Owing to its designed HDCP2.2 to HDCP1.4 convertion, VL120015 is ideal for systems that enjoy HDCP2.2 compliant Blu-ray discs or HD-content on a HDTV device with HDCP1.4 or lower standard.
-
Page 5: System Connection
HDCP2 2 . HDMI Signal: Step1. Connect a HDMI source (e.g. a Blu-ray DVD) to IN port of VL120015; Step2. Connect a HDMI display (e.g. a Blu-ray DVD) to OUT port of VL120015; Step3. Plug DC 5V 1A power adapter into the power port of VL120015. -
Page 6: Specification
1x1 HDMI Convertor 4. Specification Input Output Input 1 HDMI IN Output 1 HDMI OUT 19-pin type-A female 19-pin type-A female Connector Connector HDMI HDMI Support HDMI2.0, compliant with Support HDMI1.4 & HDMI Standard HDMI Standard HDMI1.4, 1.3& HDCP1.4 HDCP2.2 Audio HDMI embedded... -
Page 7: Panel Drawing
1x1 HDMI Convertor 5. Panel Drawing 45.50 mm 12.00 mm 15.00 mm 6. Troubleshooting & Maintenance Problems Causes Solutions Color losing or vague/ Poor quality of the optical Change for qualified HDMI double image in HDMI fiber cable cable. display Not been powered Power up the unit Power led is off, operations... -
Page 8: After Sales Service
1x1 HDMI Convertor 7. After-sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. 4) Product Limited Warranty: EET warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day the product leaves warehouse (check the SN mark on the product).
