- Page 1 User Manual VLDPSP1X2 4K 1x2 DisplayPort Splitter All Rights Reserved Version: VLDPSP1X2_2019V1.0...
-
Page 2: Safety Precaution
Statement Thanks for purchasing this product, please read this user manual carefully before using this product. The functions described in this version are updated till August, 2019. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation. -
Page 3: Panel Description
Product Introduction Thanks for choosing the 4K 1x2 DisplayPort Splitter, which can distribute one DP input to two outputs. The splitter supports DP video resolution up to 4K@60Hz 4:4:4 and multi-stream transport (MST) feature. Besides, SST mode is used for both connected displays show the same contents. -
Page 4: Technical Specification
Technical Specification Video Input Input (1) DP IN Input Connector (1) DP port DP Input Resolution Up to 4K@60Hz 4:4:4 DP Standard 1.2a HDCP Version Video Output Output (2) DP OUT Output Connector (2) DP port DP Output Resolution Up to 4K@60Hz 4:4:4 DP Standard 1.2a HDCP Version... -
Page 5: System Connection
System Connection The following diagram illustrates the typical input and output connection of the splitter: Under the MST mode Note: Output resolution: 1.two output ports support 4K@30Hz (Max) simultaneously; 2.one output port supports 4K@60 Hz, another output port only supports 2K. Under the MST mode, it does not support MAC Computer as input source device. - Page 6 Under the SST mode Note: Only under the SST mode, SPDIF (192K 7.1ch) audio can be used. Under the SST mode, When GPU as input source device, only one of output port supports audio. When MAC Computer as input source device, both of output ports support audio.
- Page 7 Panel Drawing .,..
