Steel Hand Crank Hose Reel
Instruction Manual
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when required.
Keep these instructions to assist in future servicing.
REV 08/28/18
Advertisement
Table of Contents
Related Manuals for Reelworks L430302
Summary of Contents for Reelworks L430302
- Page 1 Steel Hand Crank Hose Reel Instruction Manual WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Save these instructions in a safe place and on hand so that they can be read when required. Keep these instructions to assist in future servicing.
- Page 2 GENERAL SAFETY REGULATIONS WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors that cannot be built into this product, but must be supplied by the operator.
- Page 3 TECHNICAL DETAILS Hose Capacity Item No. Max Pressure Inlet/Outlet Material I.D. Length L430302 300Psi (20Bar) Hose is not included 5/16"/8mm 100ft/30m 1/4" L430303 Hose is not included 3/8"/9.5mm 100ft/30m 1/4" or 3/8" 300Psi (20Bar) 180 [7"] 330 [13"] 262 [10.3"] 297 [11.7"]...
- Page 4 EXPLODED AND PARTS LIST Part No. Description Q’ty Part No. Q’ty Description Frame assembly Lock pin Flange Spring Bearing assembly Washer Swivel sub-assembly Lock sleeve Screw Bolt Spring lock washer Screw Screw Support axle assembly Spring lock washer Bolt Screw Steel ball Reel-core assembly Washer...
