Summary of Contents for HAMPTON BAY MADISON StoneHenge 13H-001-5DGF
Page 1
THANK YOU We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this dining set. We Strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available...
Page 2
Table of Contents Pre-installation............Table of Contents............Planning Installation ..........Safety Information............About Symbols ............Tools required ............Warranty ..............Hardware Included............. 5 Year Frame Limited Warranty, 1 Year Table Top Limited Package Contents ............. Warranty / 1 Year Fabric Limited Warranty ....... Assembly ..............
Page 3
Pre-installation PLANNING INSTALLATION It will take 2 people about 10 minutes to complete the installation process. TOOLS REQUIRED Hex wrench (Included) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x20) Bolt (M6x25) Washer Bolt cap HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
Page 4
Pre-installation (continued) PACKAGE CONTENTS Part Description Quantity Table top Table leg Leg connector bracket...
Page 5
Assembly Assembling the table base Attaching the table top □ □ Attach the leg connector bracket (C) to each table leg (B) Place the table top (A) upside down on a at, smooth surface. with bolts (BB) and washers (CC) to form the table base. □...
Page 6
(continued) Assembly Attaching the bolt caps Leveling the table □ □ Cover all the bolts with the bolt caps (DD). Turn over the table. □ Adjust the glides at the bottom of each leg to level the table. IMPORTANT: Ensure all bolts are completely tightened before covering with bolt caps.
Page 7
Operation Using the table Checking the Stability □ □ The table is for outdoor use together with 4 dining chairs . Always put the table on at ground. □ Ensure glides are not missing before each use. □ Place seat pads in dining chairs before use. □...
Page 8
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8.00 a.m. – 6.00 p.m., EST, Monday-Friday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
