Item #751-845
Model #13H-001-4DS
USE AND CARE GUIDE
MADISON 4PC SHUTTER BACK DEEP SEATING SET
(34" Stonehenge Round Coffee Table)
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-877-527-0313
HAMPTONBAY.COM
THANK YOU
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY MADISON 13H-001-4DS
Summary of Contents for HAMPTON BAY MADISON 13H-001-4DS
- Page 1 8.00 a.m. - 6.00 p.m., EST, Monday - Friday 1-877-527-0313 HAMPTONBAY.COM THANK YOU to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Pre-assembly............Table of Contents............Planning Assembly............Safety Information............Warranty ..............Hardware Included............. 5 Year Frame Limited Warranty, 1 Year Table Top Package Contents ............. Limited Warranty ............Assembly ..............What Is Covered............What Is Not Covered............Care Instructions ............2 Safety Information DANGER: Please keep children out of the assembly area WARNING: Do not put heavy objects on the table. -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY It will take 2 people about 10 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x20) Bolt (M6x25) Washer Bolt cap Hex wrench HAMPTONBAY.COM Please contact 1-877-527-0313 for further assistance. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table top Table leg Leg connector bracket... -
Page 5: Assembly
Assembly Assembling the table base Attaching the table top □ □ Attach the leg connector bracket (C) to each table leg (B) Place the table top (A) upside down on a at, smooth surface. with bolts (BB) and washers (CC) to form the table base. □... - Page 6 Assembly (continued) Attaching the bolt caps Leveling the table □ □ Cover all the bolts with the bolts caps (DD). Turn over the table. □ Adjust the glides at the bottom of each leg to stabilize the table. IMPORTANT: Ensure all bolts are completely tightened before covering with bolt caps.
