Item #586-847
Model # 133-008-5D
USE AND CARE GUIDE
GLASS TOP DINING TABLE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY 133-008-5D
Summary of Contents for HAMPTON BAY 133-008-5D
- Page 1 8.00 a.m. - 6.00 p.m., EST, Monday - Friday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
- Page 2 Table of Contents Pre-Assembly ............3 Table of Contents............2 Planning Assembly ..............3 Safety Information............2 Hardware Included..............3 Warranty ..............2 Package Contents ..............4 2 Year Frame Limited Warranty ..........2 Assembly ..............5 ..............2 What Is Covered What Is Not Covered ..............
- Page 3 Pre-Assembly PLANNING ASSEMBLY It will take two people about 10 minutes to complete the assembly process. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Bolt (M6x15) Bolt (M6x25) Washer Bolt cap Hex wrench HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 4 Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Table rim Table leg Leg connector bracket Glass top...
- Page 5 Assembly Attaching the table legs Attaching the leg connector bracket □ Align the leg connector bracket (C) among the four table legs (B). □ □ □ Attach the table legs (B) to the table rim (A) with washers Attach the leg connector bracket (C) to the table legs (B) with washers (CC) and bolts (BB).
- Page 6 Assembly (continued) Attaching bolt caps Adding the glass top □ Cover all the bolts (AA and BB) with bolt caps (DD). □ Turn over the table. □ Place the glass top (D) into the table rim (A) to complete the assembly of the table.
- Page 7 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8.00 a.m. – 6.00 p.m., EST, Monday-Friday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
