OWNER/OPERATOR'S MANUAL
& ILLUSTRATED PARTS LIST
MODEL:
73-70680 TERRA RAKE RK260
WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
09-284 REV A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Textron JACOBSEN 73-70680 TERRA RAKE RK260
Summary of Contents for Textron JACOBSEN 73-70680 TERRA RAKE RK260
- Page 1 OWNER/OPERATOR’S MANUAL & ILLUSTRATED PARTS LIST MODEL: 73-70680 TERRA RAKE RK260 WARNING: If incorrectly used this machine can cause severe injury. Those who use and maintain this machine should be trained in its proper use, warned of its dangers and should read the entire manual before attempting to set up, operate, adjust or service the machine.
- Page 2 © 2003, TEXTRON INC...
-
Page 3: Table Of Contents
Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest life, use this product only as directed in the manual, keep it in good repair and follow safety warnings and instructions. You'll always be glad you did. Jacobsen, a Textron Company One Bob Cat Lane Johnson Creek, WI 53038-0469... -
Page 4: Introduction / Specifications
INTRODUCTION / SPECIFICATIONS TERRA RAKE DESCRIPTION The RK260 Terra Rake attaches to the Steiner power units’ front quick hitch in a minute or less. Power angle and adjustable casters allow fine tuning for spreading topsoil, crushed stone, gravel or cinders. Landscape operations include: •... -
Page 5: Safety
Your safety and the safety of others is involved. Jacobsen, a Textron Company strongly warns Signal word definitions against, rejects and disclaims any modifications, The signal words below are used to identify levels... - Page 6 SAFETY TERRA RAKE GENERAL SAFETY 1. Read and understand the Owner’s Manual before attempting to operate this machine. 2. Operate all controls from the operator’s seat. NO RIDERS. 3. Keep all shields in place and safety switches adjusted properly. 4. Do not leave equipment unattended. STOP the engine and remove the key. 5.
-
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS TERRA RAKE ASSEMBLY 1. Remove rake and attaching parts from shipping crate. 2. See Page 12 and 14, Figures 1 & 2 for parts identification and location. Attach the hitch to the rake frame with 1 X 3-1/2 bolt and nylon locknut as shown on Page 8, Photo 5. 3. -
Page 8: Installation / Features
INSTALLATION / FEATURES TERRA RAKE INSTALLATION 1. Attach Terra Rake to the “quick hitch” front lift in the usual manner. 2. Connect the hoses to the auxiliary quick couplers. NOTE: To reverse the auxiliary hydraulic lever action, switch the hoses at the quick couplers. FEATURES 1. -
Page 9: Operation
OPERATION TERRA RAKE 1. The power angle allows the operator many choices of rake position. The rake may be power angled straight ahead, to the right or left , or any position in between. 2. Gauge wheels are adjustable by moving 1/2" spacers to obtain correct working depth for various surface conditions. -
Page 10: Service
SERVICE TERRA RAKE 1. Check tines periodically for bent or misaligned tines. Straighten or replace if necessary. 2. Check tire pressures every 100 hours. Adjust to 16 lbs. maximum. 3. Grease pivot ball every 100 hours. 4. Keep it clean! Top Link...provides fine tuning for depth adjustment... -
Page 11: Parts Section
PARTS SECTION TERRA RAKE PARTS SECTION... - Page 12 HITCH PARTS TERRA RAKE FIGURE 1...
-
Page 13: Hitch Parts
HITCH PARTS TERRA RAKE FIGURE 1 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 47-009 TOP LINK 29-010 S/B GREASE FITTING 64-759.7 CHANNEL-SPRING TENSION2 41-034 SPRING,COMP 0.968 X 2.0 64163-67 WASHER-.516X1X12GA 90-0848 BOLT,1/2-13 X 6 90-1020 BOLT,5/8-11 X 2-1/2 64006-04 LOCKWSHR-HELICAL 5/8 64025-21 NUT-HEX 5/8-11... - Page 14 RAKE PARTS TERRA RAKE FIGURE 2...
-
Page 15: Rake Parts
RAKE PARTS TERRA RAKE FIGURE 2 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 62-772.7 MOUNT-RAKE TINES RK260 1 62-773.7 HOLDER-RAKE TINES RK260 1 64123-75 BOLT-3/8-16X3 HEX 64139-24 BOLT-3/8-16X1 64141-4 NUT-WLF 3/8-16 79-072 TINE, TERRA-RAKE 5/16 x 1 64025-21 NUT-HEX 5/8-11 64006-04 LOCKWSHR-HELICAL 5/8 90-1020... - Page 16 CASTER WHEELS TERRA RAKE FIGURE 3...
-
Page 17: Caster Wheels
CASTER WHEELS TERRA RAKE FIGURE 3 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 03-017 CLIP, 5/16" 64163-22 SPACER-CSTR HEIGHT ADJ 8 85-B34 BUSHING, FLANGED 29-010 S/B GREASE FITTING 62-771.7 FRAME, CASTER SWIVEL 50-082.7 FRAME-CASTER YOKE 64139-21 BLT-WLF 3/8-16X3/4 64163-06 WASHER-3/4 ID 18 53-093 WHEEL,W/13X500X6... - Page 18 Equipment from Jacobsen, a Textron company, is built to exacting standards ensured by ISO 9001 and ISO 14001 registration at all our manufacturing locations. A worldwide dealer network and factory-trained technicians backed by Textron Parts Xpress provide reliable, high-quality product support.
