  • Page 1 GET IT ON Available on the App Store Google Play User Manual M Series VideoLink The functions supported by different models may be different. If you have any questions, please feel free to contact us. Please read carefully before use it M.2023.032.E...
  • Page 2 Support : support@jennov.com Notes Before Installation 1. This manual is for reference only. The settings and functions of your device may differ from those described in this manual due to device updates etc. 2. Please check each accessory when you receive the item.

  • Page 3: Table Of Contents

    Support : support@jennov.com Catalog Chapter 1 Installation Instructions 1.1 Product Overview............01 1.2 Packing List..............04 1.3 Camera Installation............05 1.3 Device Connection............06 1.4 Connection via Switch.............07 1.5 Separate Connection Use..........08 Chapter 2 How to View the Camera via Browser? 2.1 Download PC Search Tool..........09 2.2 Batch Modify IP Method..........10...
  • Page 4 Support : support@jennov.com 3.7 Set Alarm-1..............26 3.8 Set Alarm-2..............27 3.9 Set Alarm-3..............28 3.10 Human Tracking Settings..........29 Chapter 4 How to Remotely Control via Smartphone 4.1 Mobile APP Operation.............30 Registration and Login............31 Equipment Management............32 Real-time monitoring.............33 Human tracking settings............34 Alarm and event notification..........35 Playback of TF video.............36...

  • Page 5: Product Overview

    Support : support@jennov.com Product Overview Camera Details SKU:P87HM 198mm Microphone Lens Infrared light Sensor 136mm - 01 -...
  • Page 6 Support : support@jennov.com 115mm 96mm SD Card Slot CAUTION: Please insert the Micro SD Card according to the direction shown in the picture. If it is not inserted correctly, it may get stuck in the camera. SD card port: Support micro SD card for local storage (Max 256GB).
  • Page 7 Support : support@jennov.com SKU:A76WM Note: The A76WM does not come with a TF card slot. - 03 -...

  • Page 8: Packing List

    Support : support@jennov.com Packing List Waterproof RJ45 Connector Camera Screw Pack Network Cable Power Adapter Warning Sticker User Manual Packing List Waterproof RJ45 Connector Camera Screw Pack Warning Sticker User Manual Power Adapter Network Cable Note: The package list should refer to the list of corresponding camera shape.

  • Page 9: Camera Installation

    Support : support@jennov.com Camera Installation Installation Diagram (For tracking cameras only) 1.Please refer to the schematic diagram to adjust the appropriate installation angle; 2.When multiple targets appear at the same time, the camera will preferentially track the relatively large target;...

  • Page 10: Device Connection

    Support : support@jennov.com Device Connection ·Compatible with 8MP POE NVR which support Onvif protocol ·Compatible with Hikvision POE NVR (Plug&Play) ·Compatible with Dahua POE NVR (Plug&Play) Cell phone Router Notebook Power Adapter POE1 POE2 POE3 POE4 UP LINK HD-OUT DC IN...

  • Page 11: Connection Via Switch

    Support : support@jennov.com Connection via Switch If your NVR only has one LAN port and the POE camera can't connect to the NVR directly, you can connect the camera to NVR via a POE switch. Note: If your switch is not POE switch, please plug the power supply cable of the camera.

  • Page 12: Separate Connection Use

    Support : support@jennov.com Separate Connection Use Q: How to use the camera separately? A: You can use the camera and router separately by connecting them via POE power supply. POE Power Supply Data & Data In Powar Out Router POE Camera...

  • Page 13: Download Pc Search Tool

    Support : support@jennov.com Download PC Search Tool Q: Where to find and download the PC software? A: Go to our official website: https://www.jennov.com/download/ Download "M Series Application - Windows" and run the "AjDevTools". - 09 -...

  • Page 14: Batch Modify Ip Method

    Support : support@jennov.com Batch Modify IP Method 1. Please power on the camera and plug in a network cable, then run the software “SearchTools” to search the camera IP address. 2. Modify the IP address, enable the DHCP to obtain a IP address automatically, or you can modify the IP address manually.

  • Page 15: Preview Screen With Ie Browser

    Support : support@jennov.com Preview Screen with IE Browser admin 123456 Camera 2023-04-17 Tuesday 10 : 14 : 16 After logging in, you can watch live video. Click "W:H" in the lower left corner to adjust the screen display ratio appropriately.

  • Page 16: Record To Tf Card

    Support : support@jennov.com Record to TF Card 1. Record to TF card The A76 has no SD card slot, so it does not support TF card related functions. Enter "Configuration" - "Storage" - "Timer Recording" The default is 5 minutes recording length.
  • Page 17 Support : support@jennov.com 3. TF card capacity query and formatting You need to format the TF card when you use it for the first time 4. If you want to save the video to your computer disk, you need to use the "LMS"...

  • Page 18: Playback Tf Card Video Via Browser

    Support : support@jennov.com Playback TF Card Video via Browser Note: Only P87 is supported 1. Click Playback. After selecting the video type, click the date you want to play and the video file will be displayed according to your search criteria.

  • Page 19: Download Video Data

    Support : support@jennov.com Download Video Data Note: Only P87 is supported Click Playback→ Select the date and type of video → Click on "File List" to display or download the video files based on the search criteria. Camera CAM1 2023-04-17...

  • Page 20: Alarm Settings-1

    Support : support@jennov.com Alarm Settings-1 1.Motion Detection Setting: 1) Click Settings > Events > Motion Detection, check "Enable" to enable motion detection. 2) Then set the motion detection schedule and detection area, and then click "OK". Finally, click "Save" to finish the settings.

  • Page 21: Alarm Settings-2

    Support : support@jennov.com Alarm Settings-2 5. Smart Detection Settings ( Human/Car Detection Only ) Note: P87 supports human and car detection A76 supports human detection only If you want to detect only more detailed objects with human detection, you will need to set up Smart Detection.
  • Page 22 Support : support@jennov.com PS: To set the detection area. Left click the mouse on the thumbnail and draw the detection area. (Up to 10 vertices can be clicked.) Form a closed detection area and right-click. Afterwards, click on "Save" to complete the settings.

  • Page 23: Human Tracking Settings

    Support : support@jennov.com Human Tracking Settings 1. First, use the PTZ function to adjust the camera screen to the area you want to view. 2. Enter "92" in the preset and double click " Call" to enable the auto-tracking function.

  • Page 24: Set Up Lms On Computer 1

    Download client software via https://www.jennov.com/ Download the "M Series Applicatio" and install the "LMS" for the M-Series. LMS is a client for device management and live video viewing. It is also possible to manage multiple devices at the same time.

  • Page 25: Set Lms On Computer 2

    Support : support@jennov.com Set LMS on Computer 2 2. Search for the camera IP address and add it. 1) First click on "Devices" at the top to enter Device Management. 2) Click on "Start Search" to automatically search for cameras that are already online.

  • Page 26: Set Lms On Computer 3

    Support : support@jennov.com Set LMS on Computer 3 View the live screen. Click LiveView and then double-click IP address to view. Right click with your mouse to access the menu function. Camera CAM1 2023-04-20 Wednesday 15 : 14 : 16...

  • Page 27: Recording To Local Computer Disk -1

    Support : support@jennov.com Recording to Local Computer Disk -1 1. Save the video on your computer via the "LMS" client. 2. Select the camera you need to record, click on "Record Plan" for the recording plan Set the recording time and recording mode.

  • Page 28: Recording To Local Computer Disk -2

    Support : support@jennov.com Recording to Local Computer Disk -2 Once you have selected the mode of recording you will need to select the disk to save to. Note that it is not recommended to save to the C drive. Note that using LMS to save video requires the LMS client to be running at all times on the computer side.

  • Page 29: Local Playback Of Video

    Support : support@jennov.com Local Playback of Video 1. Playback of SD Card Video: Click on "Front Playback". After selecting the date here, double-click the IP address of the camera to play back the recording according to the search criteria. 2. Local Video Playback: click "Local playback". After selecting the date here, double-click the IP address of the camera to play back the recording according to the search criteria.

  • Page 30: Set Alarm-1

    Support : support@jennov.com Set Alarm-1 1. Motion Detection Settings: 1) In LiveView, right-click on the IP address of the camera > Go to Remote Configuration > Alarms > Motion Alarms.Select "Enable" in the motion alarm to activate the motion detection function.

  • Page 31: Set Alarm-2

    Support : support@jennov.com Set Alarm-2 1) Setting the motion detection area: Left click on the thumbnail image, then drag the mouse left and right to set the area you want to detect. 2) Setting the detection schedule: Click on the date on the left or the time title bar above, or click on one of the grids to set the time you want to detect.

  • Page 32: Set Alarm-3

    Support : support@jennov.com Set Alarm-3 2. Settings for intelligent detection (human, vehicle) 1) Right-click the camera's IP address in LiveView > Remote Config > Alarm > Al analysis. 2) Check the smart detection target (human, car, etc.) that you want to detect.

  • Page 33: Human Tracking Settings

    Support : support@jennov.com Human Tracking Settings 1. First, use the PTZ function to adjust the camera screen to the area you want to monitor. 2. Enter "92" in "Preset" and double click "Call" to turn on the auto-tracking function. 3. Once set, the camera will automatically follow the target and take a picture when a humanoid target is detected in the detection area.

  • Page 34: Mobile App Operation

    Support : support@jennov.com Mobile App Operation Search "VideoLink" on apple store or google play to download the app. ·From Google play ·From Apple store ·Scan the following QR code VideoLink - 30 -...

  • Page 35: Registration And Login

    Support : support@jennov.com Registration and Login Register an account using your email address, the password is made up of 8-64 digits and must contain numbers and letters. Receive a verification code via email. (If you haven't received the verification code, please check whether it has been collected in the spam mailbox) Only mailboxes are supported for account registration at this time.

  • Page 36: Equipment Management

    Support : support@jennov.com Equipment Management 1. Click the "+" in the top right corner to add a device. 2. Enter the "Add New device" interface and select "Lan". 3. Scan the QR code on the camera. - 32 -...

  • Page 37: Real-Time Monitoring

    Support : support@jennov.com Real-time monitoring 1. Name the device and click "Bind Device". 2. Click on the screen to view the camera in real time. Camera 2023-04-12 Tuesday 11:06:51 - 33 -...

  • Page 38: Human Tracking Settings

    Support : support@jennov.com Human tracking settings Only available for P87 cameras Select "Advanced Configuration" → "Track" and click on "Start Tracking". If the target is lost, it will return to the starting tracking position after 60 seconds. Camera Camera 2023-04-12 Tuesday 11:06:51...

  • Page 39: Alarm And Event Notification

    Support : support@jennov.com Alarm and event notification 1. Enter the camera settings 2. Click into “Alarm” 3. Click on the IVS to select the type of detection, effective time of the detection and delineate the detection area Camera 2023-04-12 Tuesday 11:06:51...

  • Page 40: Playback Of Tf Video

    Support : support@jennov.com Playback of TF video Note: The A76 has no SD card slot, so it does not support TF card-related functions Set the detection area: In the thumbnail, click with the left mouse button to draw the detection area. (You can click on up to 10 vertices).

  • Page 41: Function Tey Introduction-1

    Support : support@jennov.com Function Tey Introduction-1 Screenshot: screenshots are saved inside the APP's photo album. Camera Recording: the recording package is inside the album of the APP. Speaker: when turned on, you can hear the sound on the side of the camera.

  • Page 42: Function Key Introduction-2

    Support : support@jennov.com Function Key Introduction-2 Preset position: app can set a total of 6 preset position. Set: Adjust the camera toward the position you want to view and click on Set, enter"1" and click Camera on the first picture below, go to the No.2 position you want to watch, click on Set and enter "2"...

  • Page 43: Function Key Introduction-3

    Support : support@jennov.com Function Key Introduction-3 Camera Camera Camera Camera 2023-04-12 Tuesday 11:06:51 2023-04-12 Tuesday 11:06:51 2023-04-12 Tuesday 11:06:51 Advanced Configuration Track:adjustable dome zoom, preset position recall, with on and off tracking function. Cruise: with the ability to quickly start and stop the cruise function.

  • Page 44: Function Key Introduction-4

    Support : support@jennov.com Function Key Introduction-4 Product information; contains product ID, serial number, product model firmware, firmware date, firmware version number Audio and video; "screen flip" "video capture" "video encoding" "audio settings" "Title settings" "Light settings" Alarm: "Intelligent analysis", "Alarm push"...

  • Page 45: Where Is The Reset Button

    If you can rotate it, there may be a problem with the camera. 3) Our official website (https://www.jennov.com) and then use Ajdevtools to search. - 41 -...

  • Page 46: The Terracotta Lobby Lights Up At Night

    Support : support@jennov.com Q: The infrared light does not come on even at night? A: 1) If it is still bright around at night, the infrared indicator may turn off automatically. 2) The camera's IR-CUT reacts slowly and the automatic switcho- ver fails due to the humidity and luminosity of the weather, etc.

  • Page 47: Lan Cable Options

    Support : support@jennov.com Q: How to choose a LAN cable A: For LAN cables when using the PoE function, it is recommended to use an 8-core LAN cable. For Cat5 use LAN cables up to 30 metres and for Cat6 use LAN cables up to 50 meteres.

  • Page 48: How To Connect It To Your Nvr

    Support : support@jennov.com How to connect it to your NVR? ★★★NOTE: Please be sure to modify the IP address of the camera before connecting the camera. 1. Download the M-series software 'AjDevTools': https://www.jennov.com/ 2. Run the software to search the camera IP address.

  • Page 49: How To Add If Nvr Is Dual Ip

    Support : support@jennov.com How to add if NVR is Dual IP? 1. Connect the Dual IP NVR to the monitor to check the camera IP address of the NVR port. 2. Download the M-series software "AjDevTools". 3. Connect the camera to your router and run the software on the computer to manually modify the IP address.

  • Page 50: Rtsp Setting

    Support : support@jennov.com The RTSP URL format for the Anjavision IPC is as follows (assuming an IPC IP of 192.168.0.123) Main code stream: rtsp://admin:123456@192.168.0.123/stream0 Sub-stream: rtsp://admin:123456@192.168.0.123/stream1 The RTSP URL above, if audio is enabled, will contain both video and audio in the stream data.
  • Page 51 12-month warranty from the order date on. After finish filling or scanning, please take a picture and send it to the email(support@jennov.com). Then your free warranty will take effect ! During the warranty period, if any parts of product are damaged, please contact us immediately and we will provide satisfactory resolution.
