Summary of Contents for Oerlikon Citotig 400
- Page 1 IM3181 12/2022 REV00 CITOTIG 400 OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-260 Bielawa, Poland...
-
Page 2: Table Of Contents
12/05 THANK YOU! For choosing the QUALITY of the Lincoln Electric products. Please check packaging and equipment for damage. Claims for material damaged in shipment must be notified immediately to the dealer. For ease of use, please enter your product identification data in the table below. Model Name, Code & Serial Number can be found on the machine rating plate. -
Page 3: Technical Specifications
Technical Specifications NAME INDEX CITOTIG 400 W100000300 INPUT Input Voltage U EMC Class CITOTIG 400 400V ± 15%, 3-phase 1eff 1max CITOTIG 400 16,9A 24,9A Input Power at Rated Cycle Input Amperes I PF(400V) 1max 4,0 kVA @100% (GTAW) ... -
Page 4: Eco Design Information
Efficiency and idle power consumption: Efficiency when max power Index Name Equivalent model consumption / Idle power consumption W100000300 CITOTIG 400 88% / 22W No equivalent model Idle state occurs under the condition specified in below table IDLE STATE Condition Presence... - Page 5 Typical gas usage for MIG/MAG equipment: DC electrode positive Wire Wire Feeding Gas flow Material type diameter Shielding Gas Current Voltage [m/min] [l/min] [mm] Carbon, low 0,9 ÷ 1,1 95 ÷ 200 18 ÷ 22 3,5 – 6,5 Ar 75%, CO alloy steel Aluminium 0,8 ÷...
-
Page 6: Electromagnetic Compatibility (Emc)
Provided that the public low voltage system impedance at the point of common coupling is lower than: 68 mΩ for the CITOTIG 400. This equipment is compliant with IEC 61000-3-11 and IEC 61000-3-12 and can be connected to public low voltage systems. -
Page 7: Safety
Safety 01/11 WARNING This equipment have to be used by qualified personnel. Be sure that all installation, operation, maintenance and repair procedures are performed only by qualified person. Read and understand this manual before operating this equipment. Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or equipment damage. Read and understand the following explanations of the warning symbols. - Page 8 WELDING SPARKS CAN CAUSE FIRE OR EXPLOSION: Remove fire hazards from the welding area and have a fire extinguisher easily accessible. Welding sparks and hot materials from the welding process can easily go through small cracks and openings to adjacent areas. Do not weld on any tanks, drums, containers, or material until the proper steps have been taken to insure that no flammable or toxic vapors will be present.
-
Page 9: Introduction
The This machine must be located where there is free welding machine CITOTIG 400 must be connected to a circulation of clean air without restrictions for air correctly installed plug-in socket with an earth pin. - Page 10 7. Negative Output Socket for the Welding Circuit: Controls and Operational Features Depending on the process to connecting: Process Symbol Description GTAW TIG Torch Electrode Holder with lead / SMAW work lead depending on the require configuration Gauge Torch / work lead GAUGE depending on the require configuration...
- Page 11 11. Fuse F1: Use the 2A/400V (6,3x32mm) slow-blow Welding GTAW Process fuse. See "Spare Parts" chapter. CITOTIG 400 can be used to GTAW process with DC (-). CITOTIG 400 does not include the torch to GTAW 12. Fuse F2: Use the 2A/400V (6,3x32mm) slow-blow welding, but the one can be purchased separately.
- Page 12 Gouging Gas Connection CITOTIG 400 does not include the torch holder with lead necessary for gauging, but the one can be purchased WARNING separately. See "Accessories" chapter. CYLINDER may explode if damaged. Always fix the gas cylinder securely in an...
- Page 13 Transport & Lifting Maintenance WARNING WARNING Falling equipment can cause injury and For any repair operations, modifications or maintenances, it is recommended to contact the nearest Technical damage to unit. Service Center Lincoln Electric. Repairs modifications performed by unauthorized service or personnel will cause, that the manufacturer’s warranty will be lost.
- Page 14 Lincoln Electric affect the results obtained in applying these types of fabrication methods and service requirements. Subject to Change – This information is accurate to the best of our knowledge at the time of printing. Please refer www.oerlikon.com for any updated information. English English...
-
Page 15: Weee
WEEE 07/06 Do not dispose of electrical equipment together with normal waste! In observance of European Directive 2012/19/EC on Waste Electrical and Electronic Equipment (WEEE) and its implementation in accordance with national law, electrical equipment that has reached the end of its life must be collected separately and returned to an environmentally compatible recycling facility. -
Page 16: Accessories
Accessories TIG PREMIUM TORCHES AIR PROTIG IIIS 10 RL W000382715-2 W000382716-2 PROTIG IIIS 20 RL W000382717-2 W000382718-2 PROTIG IIIS 30 RL W000382719-2 W000382720-2 PROTIG IIIS 40 RL W000382721-2 W000382722-2 PROTIG NGS 10 EB W000278394-2 W000278395-2 PROTIG NGS 20 EB W000278396-2 W000278397-2 PROTIG NGS 30 EB W000278398-2... -
Page 17: Connection Diagram
Connection Diagram English English... -
Page 18: Dimension Diagram
Dimension Diagram English English...
