- Page 1 ECONO CONVEYOR SEC-CCY Read This Manual before Operating OPERATION MANUAL Notice: Read through this operation manual before operating the conveyor. Always observe cautionary items written in this manual strictly. Keep this manual at a place where you can refer to it at any time.
- Page 2 INTRODUCTION Thank you for purchasing the “ECONO COVEYOR”. This operation manual describes the conveyor’s functions, how to operate it, and the precautions when using it. Please read this manual thoroughly in order to understand the features of this conveyor better and use it more efficiently. Features Because of aluminum frame and polyurethane belt, the structure is light and compact.
-
Page 3: Table Of Contents
CONTENTS Related Safety Information ....................1 Safety-Precaution Indications ......................... 1 Safety-Precautions ..........................2 Precaution Labels ............................ 5 Name and Function of Each Part ..................8 Name of Each Part on Conveyor ......................8 Name and Function of Each Part in Control Box O peration Screen .......... -
Page 4: Related Safety Information
1 Related Safety Information Improper operation of this product can cause failure or accident. Be familiar with safety precautions described in the operation manual and also be careful for related operations. Safety-Precaution Indications Safety-precaution indications which recorded in this manual are divided into 3 kinds. DANGER Ignorance of this precaution may cause serious injuries even death. -
Page 5: Safety-Precautions
1 Related Safety Information Safety-Precautions DANGER ●Any operator is forbidden to sit on the conveyor Never attempt to sit on the conveyor. If an operator sits on the conveyor, the conveyor will be unstable and operator may fall down and get injured. ●Maintenance is not allowed during conveyor running Never attempt to maintain the conveyor while it is running. - Page 6 1 Related Safety Information ●Do not touch the conveyor belt while the conveyor is running Never put your hands inside the conveyor belt while it is running, or the risk of getting hands caught or pinched in the conveyor driving rollers may be caused. 。...
- Page 7 1 Related Safety Information ● Stop all devices linked to the conveyor during check Before check, maintain, modify, clean or lubricate the conveyor in the conveyor’s moving range, be sure to shut down not only the conveyor itself but also all devices linked to it. A mistaken operation will cause serious casualty.
-
Page 8: Precaution Labels
1 Related Safety Information Precaution Labels ■Kinds of Precaution Labels ※ I ncluding some precaution labels which are not used on this conveyor. ● Caution for high voltage electric shock Make sure to turn off the breaker of control box while maintenance. - Page 9 1 Related Safety Information ● Caution for danger of chopping During working in operating area for maintenance or other purposes, do not touch rotary axis, gear, pulley belt which have danger of enfolding you. Turn off power supply while working. ●...
- Page 10 1 Related Safety Information ■Locations of Precaution Labels The locations of precaution labels are marked on the following picture. ●Picture of Conveyor CAUTION The conveyor belt may be charged by static electricity. Caution,electric shock...
-
Page 11: Name And Function Of Each Part
各部位名称和功能 2 Name and Function of Each Part Name of Each Part on Conveyor ① Conveyor Belt This is a special belt made of polyurethane resin. ② Control Box This box is used to set and operate the conveyor. ③ Motor Reducer The power supply of conveyor.The speed varies according to the type of conveyor. -
Page 12: Name And Function Of Each Part In Control Box O Peration Screen
2 Name and Function of Each Part Name and Function of Each Part in Control Box（Operation Screen） ■Standard Specification（CC-4B III） ① Power Switch Turn on/off the power of conveyor. ② Speed Setting Switch This switch is used to set the speed of product delivery. Setting range: 1 ～... -
Page 13: Operation Method
3 Operation Method 3-1 Adjustment When assembling a conveyor, please fix the castors and do the following adjustments. ■ Height Adjustment Please refer to the picture, first loosen the mounting nuts by a monkey wrench, then rotate the hand wheel to adjust the height of conveyor. -
Page 14: Power Supply
3 Operation Method 3-2 Power Supply The following are the connecting methods of power wire and conveyor start signal wire. DANGER ・ Please turn off the power (supply side) before wire connecting. ・ For instruction of connecting conveyor start signals （... - Page 15 3 Operation Method Signal Table Signal Note Cooling Fan （ 9 0W ） Cooling Fan （ 9 0W ） Motor rotation direction control common terminal Motor rotation direction control forward terminal Motor rotation direction control reverse terminal Motor Power Output Motor Power Output Motor Power Output S-Phase of AC Input...
-
Page 16: Maintenance And Check
4 Maintenance and Check Open the chain cover and grease the chains with bush every 6 months. CAUTION After maintenance or check, assemble the chain cover back to its place. Or, operator may get chopped by the chains. -
Page 17: Reference Data
5 Reference Data 5-1 Mechanical Specification Standard Specification Maximum Overall Total Belt Width Height Payload Weight Model Power Supply Length Speed (Type A) （ ） （ ） （ ） （ ） (mm) SEC2000-3CCX SEC2000-4CCX 2000 SEC2000-5CCX SEC2000-6CCX SEC3000-3CCX Setting Standard SEC3000-4CCX ～... -
Page 18: Part List
5 Reference Data Standard Specification (Speed Variable Motor) Drawing of Maximum Payload ） （ Speed （ m /min. ） Speed － M aximum Payload Diagram 5-2 Part List Name Specification Supplier Quantity Code No. Single-Phase Induction M 9 1 X 4 0 G V 4 D G A Panasonic Motor （... -
Page 19: Electric Drawing
5 Reference Data 5-3 Electric Drawing Electric Drawing of Quick Conveyor （ S tandard Specification ） ※ 1 AC200V Specification External switch OPEN: Permanent action External switch Close: Intermittent action Rotation direction shift terminal （ ） C OM,CW,CCW SEC conveyor can not use Please do not alter the COM Jumper Usage method of SW terminal ※... -
Page 20: General Drawing
5 Reference Data 5-4 General Drawing ■ － 2 000 、 3 000... - Page 21 5 Reference Data ■ － 4 000 、 5 000...
- Page 22 A ll copyrights regarding this manual belong to STAR SEIKI Co., Ltd. ・ Reproduction, translation or adaption of this manual in whole or part without consent from STAR SEIKI shall be an infringement of copyright. T hese specifications are subject to change without prior notice.
