Use this product according to this instruction manual. Please keep this instruction manual for future reference.
GENERAL:
Wheelock's Series RSSWP Strobes can provide a non-synchronized strobe signal when connected directly to a Fire Alarm Control
Panel (FACP), or provide a synchronized strobe signal when used in conjunction with a Sync Module (SM), Dual Sync Module
(DSM), or Wheelock's Power Supplies. The RSSWP strobe appliance is UL Listed under Standard 1638 (Visual Signaling
Appliances) for indoor/outdoor use, fire protective service. The Series RSSWP Strobe Appliances are also ULC Listed under
Standard CAN/ULC-S526-02 for Visual Signaling Appliances. The strobe has a 75 candela intensity on axis at -35 o C and low
current draw. For outdoor applications the RSSWP must be wall mounted to a Weatherproof Backbox (WPSBB). The strobes use a
Xenon flashtube with solid state circuitry enclosed in a rugged Lexan lens to provide maximum visibility and reliability for effective
visible signaling. All inputs are polarized for compatibility with standard reverse polarity supervision of circuit wiring by a FACP.
NOTE: "Lexan" is a registered trademark of General Electric Company.
NOTE: All CAUTIONS and WARNINGS are identified by the symbol
WARNING: THE RSSWP STROBE APPLIANCE IS A "FIRE ALARM DEVICE - DO NOT PAINT."
NOTE: All Canadian Installations should be in accordance with the Canadian Standard for the Installation of Fire Alarm Systems -
CAN/ULC-S524-01 and Canadian Electrical Code, Part 1. Final acceptance is subject to Authorities Having Jurisdiction.
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY. FAILURE TO COMPLY WITH ANY OF THE
FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION,
INSTALLATION AND/OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD
RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.
SPECIFICATIONS:
Model
(VDC/VRMS)
RSSWP-2475W
NOTES:
1. Strobes will produce 1 flash per second over the "Regulated Voltage" range.
2. All models are UL/ULC Listed for indoor and outdoor use with a temperature range of -31°F to +150°F (-35°C to +66°C) and
maximum humidity of 93% RH, ± 2%.
NOTE:
THE MAXIMUM WIRE IMPEDANCE BETWEEN STROBES SHALL NOT EXCEED 35 OHMS.
MAXIMUM NUMBER OF STROBES ON A SINGLE NOTIFICATION APPLIANCE CIRCUIT SHALL NOT EXCEED 47.
Copyright 2004 Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
SERIES RSSWP STROBE WEATHERPROOF APPLIANCE
(2-WIRE WALL MOUNT VERSION)
Regulated
Voltage Range Limit
Voltage
Per UL 1638
(VDC/VRMS)
24
16.0-33.0
. All warnings are printed in bold capital letters.
Table 1: UL/ULC Ratings
Voltage Range Per
CAN/ULC-S526-02
(VDC/VRMS)
20.0-31.0
UL Rated Strobe
Candela (cd)
At 25°C
At -35°C
180
75
ULC Rated
Strobe Candela
(cd)
180
THE
P84135 G
Sheet 1 of 6
