Wheelock AS Series Installation Instructions Manual

273 Branchport Avenue
Long Branch, NJ 07740
(800) 631-2148
www.wheelockinc.com
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Wheelock's AS Audible Strobe Appliances are the industry's first 2-wire horn strobe alarm appliances that can provide a selectable
continuous or code 3 horn tone and continuous strobe when connected directly to the Fire Alarm Control Panel (FACP), or provide a
synchronized code 3 and synchronized strobe when used in conjunction with a Sync Module (SM), Dual Sync Module (DSM) or
Power Supply (PS-12/24-8). The AS Appliances are UL Listed under Standard 1971 for Emergency Appliances for the Hearing Impaired
and UL Standard 464 for Audible Signal Appliances. They are listed for ceiling mounting and indoor use only and equipped with a
Universal Mounting Plate (UMP) that can be mounted to single-gang, double-gang and 4" backbox, 100mm European backbox or SHBB
surface backbox (See Mounting Options). The AS Appliances use a xenon flashtube with solid state circuitry enclosed in a rugged
Lexan® lens to provide maximum visibility and reliability for effective visible signaling.
Series AS Appliances can be field set to provide either High (HI) dBA, Medium (MED) dBA or Low (LO) dBA sound output.
All Series AS models are designed for use with either filtered DC (VDC) or unfiltered Full-Wave-Rectified (FWR) input voltage. All
inputs are polarized for compatibility with standard reverse polarity supervision of circuit wiring by a Fire Alarm Control Panel (FACP).
NOTE: The code 3 horn incorporates the temporal pattern (1/2 second on, 1/2 second off, 1/2 second on, 1/2 second off, 1/2 second
on, 1-1/2 off and repeat) specified by ANSI/NFPA for standard emergency evacuation signaling. The code 3 horn should be used only
for fire evacuation signaling and not for any other purpose.
NOTE: All CAUTIONS and WARNINGS are identified by the symbol
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT. FAILURE TO COMPLY
WITH ANY OF THE FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER
APPLICATION, INSTALLATION AND/OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH
COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.
WARNING: THE AUDIBLE STROBE APPLIANCES MUST BE FIELD SET TO THE DESIRED dBA SOUND OUTPUT LEVEL
BEFORE THEY ARE INSTALLED. THIS IS DONE BY PROPERLY INSERTING A JUMPER PLUG IN ACCORDANCE WITH
THESE INSTRUCTIONS. INCORRECT SETTINGS WILL RESULT IN IMPROPER PERFORMANCE, WHICH COULD RESULT IN
PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.

SPECIFICATIONS:

Models
AS-2415C
AS-2430C
AS-2475C
AS-24100C
NOTE: THE MAXIMUM WIRE IMPEDANCE BETWEEN STROBES SHALL NOT EXCEED 35 OHMS. THE MAXIMUM NUMBER
OF STROBES ON A SINGLE NAC CIRCUIT SHALL NOT EXCEED 47.
Copyright 2001 Wheelock, Inc. All rights reserved.
www.PDF-Zoo.com
Thank you for using our products.
INSTALLATION INSTRUCTIONS
SERIES AS AUDIBLE STROBE APPLIANCES
(CEILING MOUNT VERSION)
Table 1: UL Ratings
Regulated
Voltage
(VDC/VRMS)
24
24
24
24
firealarmresources.com
. All warnings are printed in bold capital letters.
Voltage
Range
(VDC/VRMS)
16.0-33.0
16.0-33.0
16.0-33.0
16.0-33.0
Strobe
Candela
(cd)
15
30
75
100
P84024 D
Sheet 1 of 8
