Wheelock AC-MAX-A Installation Instructions

273 Branchport Ave.
Long Branch, NJ 07740
(800) 631-2148
www.wheelockinc.com
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Wheelock's Series Max Strobes are UL 1638 Listed for indoor or outdoor use. They are high intensity visible warning
appliances that are designed for use in either stationary locations or mobile equipment. All Series Max Strobes are weather-
resistant. They produce a powerful double flash light burst at the rate of 60 double flashes per minute. Series Max Strobes can
be installed using 1/2-inch pipe mount, surface mount or flange mount (an integral 1/2-inch pipe thread, a flange mounting ring
and a weather-resistant gasket are included with each unit). They can also be mounted to standard 4-inch square electrical boxes,
100mm European boxes and Wheelock's WBB outdoor box. There are four models of Series Max Strobes: The AC-MAX and
AC-MAXS Models for 120VAC applications and the DC-MAX and DC-MAXS Models for use with any DC voltage from
10.5VDC to 31.0VDC. The AC-MAX and DC-MAX are strobe only models while the AC-MAXS and DC-MAXS models offer
a steady-light feature along with the strobe operation. All models are available with either clear, amber, red, or blue lens color.
NOTE : All CAUTIONS and
WARNING: READ THESE INSTRUCTIONS CAREFULLY.
FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION,
INSTALLATION AND/OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD
RESULT IN PROPERTY DAMAGE, SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.

SPECIFICATIONS:

Model Lens
Code Color
AC-MAX-A
Amber
AC-MAXS-A
AC-MAX-B
Blue
AC-MAXS-B
AC-MAX-C
Clear
AC-MAXS-C
AC-MAX-R
AC-MAXS-R
DC-MAX-A
Amber
DC-MAXS-A
DC-MAX-B
Blue
DC-MAXS-B
DC-MAX-C
Clear
DC-MAXS-C
DC-MAX-R
DC-MAXS-R
Model Code
AC-MAXS
DC-MAXS
NOTES:
1. Temperature range for all models is -31°F to +151°F (-35°C to +66°C)
2. Lens colors conform to SAE J578D specifications.
3. Flash energy and flash rate are specified for double flash operation.
Copyright 2002 Wheelock, Inc. All rights reserved.
Thank you for using our products.
SERIES MAX INDUSTRIAL STROBES
INSTALLATION INSTRUCTIONS
WARNINGS are identified by the symbol
Table 1A: Ratings per UL
Minimum
Voltage Voltage
102
VAC
Red
Red
Table 1B: Steady-light Specifications
. All warnings are printed in bold capital letters.
FAILURE TO COMPLY WITH ANY OF THE
Rated Maximum
Voltage
120 127
VAC VAC
10.5-31.0
VDC
Rated Voltage
120VAC
10.5-31.0VDC
Input
Current
0.20A @
120VAC
1227mA @ 10.5VDC
1010mA @ 12VDC
470mA @ 24VDC
344mA @ 31VDC
Current mA
120mA
665mA
Flash
Rate
60/Min
Typ.
60/Min
Typ.
P83857 H
Sheet 1 of 4
