- Page 1 OperatOr and parts Manual Conventional Auger Model 1066 & 1076 112010 SZ000252...
-
Page 3: Table Of Contents
Table of Contents - 1066 & 1076 Conventional Auger Table of Contents Introduction ..........................4 Safety ............................5 • Safety ..........................5 • General Safety ........................5 • Operation Safety ......................5 • Transport Safety .......................6 • Electrical Safety ........................6 • Safe Operation Instructions ....................6 Assembly ............................8... -
Page 4: Introduction
Abuse or modifications to the auger that change the performance other than original factory specifications void the warranty. Farm King reserves the right to make product improvements to the equipment at any time. It shall not be obligated to make such changes to machines already in service. -
Page 5: Safety
Safety - 1066 & 1076 Conventional Auger Safety Safety Instructions An Operator‘s Manual is furnished with each grain auger. Additional or replacement manuals are available. Do not operate the unit before reading and understanding the Operator‘s Manual. Understand the operating procedures below to avoid personal injury or death. -
Page 6: Transport Safety
Safety - 1066 & 1076 Conventional Auger Transport Safety Care must be used when moving or transporting the auger. Accidental tipping or upending of an auger can occur and may cause serious injury or death to the operator or bystanders. - Page 7 Safety - 1066 & 1076 Conventional Auger Upending hazard. 1 - Never mover the auger manually - use a vehicle. 2 - Always have downward weight on the intake end of the auger. 3 - Always test the downward weight before releasing the auger from the vehicle or hold down.
-
Page 8: Assembly
Assembly - 1066 & 1076 Conventional Auger 1066 Trussing 1076 Trussing... - Page 9 Assembly - 1066 & 1076 Conventional Auger 1066 Model NOTE: Use a 3/8" x 1-1/4" Grade 2 shear bolt. Using other than a Grade 2 bolt may result in damage to the drive components. 1076 Model Keep all shields in place during operation.
-
Page 10: And 6 Bolt Hub Assembly
Assembly - 1066 & 1076 Conventional Auger Keep all shields in place during operation. 4 and 6 Bolt Hub Assembly Head Drive Assembly... -
Page 11: Assembly Instructions
Assembly - 1066 & 1076 Conventional Auger Assembly Instructions One must use extreme caution when assembling this auger. Lifting devices (i.e. loader tractor, forklift, etc.) are required as well as various wrenches and tools. Assemble the auger on a flat surface. - Page 12 Assembly - 1066 & 1076 Conventional Auger 8. Assemble the truss risers as shown to the right, using two supports (Ref. #27), one 3/8" x 1" bolt, nut and lockwasher combination (Ref. #32), one cross brace (Ref. #28) and two 3/8" x 1-1/4" bolt, nut and lockwasher combinations (Ref.
- Page 13 Assembly - 1066 & 1076 Conventional Auger 10. Assemble the undercarriage 1066 Model Remove track stop pin (Ref. #118) from the end of the track, install track car (Ref. #50) onto the top end of the track, and then replace track stop pin prior to using the auger. Failure to do so could cause the auger to collapse.
- Page 14 Assembly - 1066 & 1076 Conventional Auger 11. Mount the winch (Ref. #49) using the 3/8" x 1" bolt, nut and lockwasher combinations (Ref. #48) and thread the cable as instructed below. Fasten the lift cable (Ref. #56) to the tube by the tube splice with a cable thimble and two cable clamps (Ref.
-
Page 15: Assembly Instructions - Pto Drive
Assembly - 1066 & 1076 Conventional Auger Assembly Instructions - PTO Drive Attach the Implement Input Driveline (IID) (Ref. #81) to the gear box with a 7/16" x 2-1/2" spiral pin (Ref. #82). 2. Mount the gear box shield (Ref. #78) using 1/2" x 3/4" bolt and lockwasher (Ref. #77). -
Page 16: Parts
Parts - 1066 & 1076 Conventional Auger Parts List - 1066 and 1076 Conventional Auger Part No. Description SZ2937033 Auger Tube (Top Half) w/ Head & Bearing Brackets SZ103640 Auger Tube (Top Half) w/ Head & Bearing Brackets* SZ2937040 Auger Tube (Top Half) w/ Head & Bearing Brackets SZ103618 Auger Tube (Top Half) w/ Head &... - Page 17 Parts - 1066 & 1076 Conventional Auger Part No. Description SZ127012 WSHR LCK 1/2 SZ126067 BLT HHCS 3/8-16UNC 1-1/4 SZ127009 WSHR LCK 3/8 SZ125007 Nut Hex 3/8-16UNC SZ2038351 Cable Truss Support SZ2031360 Truss Cross Brace SZ2038322 1/4" Truss Cable w/ Eye Bolt SZ2038365 3/16"...
- Page 18 Parts - 1066 & 1076 Conventional Auger Part No. Description SZ6001403 1/4" x 2" Cotter Pin w/ 1" x 14 ga Bushing 3/8" x 1-3/4" Bolt, Nut & Lockwasher w/1-1 /4" x 14 SZ6003876 Ga. Bushing SZ0114415 15" 4 Bolt Wheel SZ0116615 15"...
- Page 19 Parts - 1066 & 1076 Conventional Auger Part No. Description SZ8481808 Head Drive - Cover SZ126051 BLT HHCS 5/16-18UNC 1-1/2 G5 SZ127010 WSHR LCK 5/16 SZ125006 5/16" Hex Nut 18 UNC Grade 5 SZ8401809 Access Plug SZ2010043 1-1/4" Steel Bearing w/Set Screw...
- Page 20 Parts - 1066 & 1076 Conventional Auger Part No. Description SZ2029605 Stop Lift Flag Arm Assembly SZ6003531 5/32" x 1-1/4" Cotter Pin SZ102436 Nut LCK #10-24UNC Nylock SZ126026 BLT HHCS #10-24UNC 3/4 SZ126047 BLT HHCS 5/16-18UNC 1 G5 SZ125034 Nut LCK 5/16-18UNC Squeeze...
-
Page 21: Decals
Parts - 1066 & 1076 Conventional Auger Parts List - Decals (decal location drawing available upon request) Part No. Description SZ06001 Made in the USA SZ06010 "WARNING" Do not operate the unit before reading the operator's manual SZ06018 "NOTICE" Do not operate when empty during break-in period SZ06023 "WARNING"... -
Page 22: Pto Drive
Parts - 1066 & 1076 Conventional Auger Parts List - SZ0161348B - PTO Drive Ref No. Part No. Description SZ0161348B Complete IID - 7/16" Cross Hole - 48" Closed Length SZ01613481B Tractor Half w/ 5-7/8" O.D. Bell Shield (Uni-Shield) SZ016134815B Machine Half w/ 5-7/8" O.D. Bell Shield (Uni-Shield) SZ195-1406A 14N 1-3/8"... -
Page 23: 6005 Gear Box
Parts - 1066 & 1076 Conventional Auger Parts List - SZ0168131 - Prairie Gear 6005 Gear Box Ref No. Part No. Description SZ0168131 Prairie Gear w/ 1-1/4" x 1-1/4" x 1" - 7/16" Pinhole SZPG-1207 Gear - 17 Tooth SZPG-4645B Input Shaft - 7/16"... -
Page 24: Warranty
Repair Parts Limited Warranty Buhler Industries Inc. warrants Farm King replacement parts purchased after the expiration of the Buhler Industries Inc. Limited Warranty, and used and serviced as provided for in the Operator’s Manual, to be free from defects in materials or workmanship for a period of thirty (30) days from the invoice date for the parts. - Page 25 Warranty Requirements To be covered by warranty, each Farm King new product must be registered with Buhler Industries Inc. within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Buhler Industries Inc.
- Page 26 Warranty - 1066 & 1076 Conventional Auger (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and you may also have other rights, which vary from province to province or state to state.
- Page 28 www.farm-king.com 1330 43rd Street NW Fargo, ND USA 58102 Ph.: 701.282.7014 | Fax: 701.282.5865 Toll Free: 888.524.1004 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2010 Buhler Trading Inc. Printed in USA. TSX:BUI a division of Buhler Industries Inc.
