Miroir Micro Pro Quick Start Manual page 3

Your Miroir Micro Pro Projector
K
G
H
A
2
M L J I
C
F
E
D
B
A
Projection Lens
B
Cooling Vent - IMPORTANT: Do not cover or block airfl ow to the vent.
C
Focus Controls - Turn wheel to adjust focus.
D
Tripod Mount - Will fi t a standard sized tripod screw. Tripod not included.
E
Rubber Foot Pads - Provides stability and proper airfl ow to cooling vents.
F
Battery Indicator Lights - Lights fl ash in turn as the device charges.
The battery is fully charged when all the lights illuminate and no
longer fl ash.
G
Volume Controls - Increase/decrease the volume output of the projector.
H Power Button - Press and hold for 3 seconds to power the projector on or
off . Briefl y press to check battery life on the projector. Battery life will
be displayed by the number of lit battery indicator lights.
I
Power Port - Connect included AC Adapter/Charger for power. Fully
charge battery before the fi rst use (approx. 4-5 hours).
J
Reset Button - Press to reset projector.
Audio Out (3.5mm) - (Optional) Connect an external speaker or
K
headphones.
L HDMI Video Input - Connect an HDMI cable to a device that supports
HDMI video output.
M USB Power Output - Connect a USB power cable to provide power to a
HDMI streaming stick. Cannot be used for video input.
3
