- Page 1 TV WALL MOUNT RF-HTMT15 ASSEMBLY GUIDE Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
• Improper installation may cause property damage or personal injury. If you do not understand these directions, or have doubts about the safety of the installation, contact Customer Service or call a qualified contractor. Rocketfish is not responsible for damage or injury caused by incorrect installation or use. -
Page 3: Features
RF-HTMT15 Features • Fits most TVs with 32 - 55" (81.28 to 139.7 cm) screens and holds up to 80 lbs. (36.3 kg) • Thin profile design mounts the TV only 2.2" from the wall • Tilt adjusts from 5° to -10° to reduce glare without the need for tools •... -
Page 4: Tools Needed
Tools needed You will need the following tools to assemble your new TV wall mount: Level Pencil Drill Edge-to-edge Phillips screwdriver stud finder 7/32” (5.5 mm) wood drill bit for wood stud wall Socket wrench with Measuring tape 1/2” (13 mm) socket or Hammer adjustable wrench 3/8”... - Page 5 RF-HTMT15 TV hardware bag Hardware Hardware M4 × 12 mm screw M6 × 35 mm screw M8 × 16 mm screw M4 × 35 mm screw M4 washer M8 × 20 mm screw M6/M8 washer M8 × 30 mm screw 22 mm spacer M8 ×...
-
Page 6: Installation Instructions
Concrete Installation Kit CMK1 (not included) Contact customer service at 1-800-620-2790 to inquire about these additional parts. Concrete anchors (Fischer UX10 x 60R) Installation instructions STEP 1 - Determining whether your TV has a flat back or an irregular or obstructed back Carefully place your TV screen face-down on a cushioned, clean surface to protect the screen from damages and scratches. - Page 7 RF-HTMT15 • Irregularly-shaped back: There is a gap between the brackets and some part of the back of your TV. You will need spacers (I or J) when assembling the wall mount. Remove the TV brackets (B and C). Need help? Call 1-800-620-2790 (U.S. and Canada)
- Page 8 STEP 2 - Selecting screws, washers, and spacers Select the hardware for your TV (screws, washers, and spacers). A limited number of TVs come with mounting hardware included. (If there are screws that came with the TV, they are almost always in the holes on the back of the TV.) If you don't know the correct length of the mounting screws your TV requires, test various sizes by hand threading the screws.
- Page 9 RF-HTMT15 STEP 3 - Option 1: Attaching the mounting hardware to TVs with a flat back You’ll need Screws Washers M (4) E (4) L (4) O (4) G (4) Level (B and C) TV Phillips screwdriver brackets P (4)
- Page 10 STEP 3 - Option 2: Attaching the mounting hardware to TVs with irregular or obstructed backs You’ll need Washers Screws F (4) N (4) Q (4) G (4) H (4) R (4) S (4) I (4) K (4) (B and C) TV Brackets J (4) Level...
- Page 11 RF-HTMT15 STEP 4 - Determining wall-mount location You’ll need Pencil Measuring tape Notes: • For more detailed information on determining where to drill your holes, visit our online height-finder at: http://mf1.bestbuy.selectionassistant.com/heightfinder • Your TV should be high enough so your eyes are level with the middle of the screen (normally, 40 to 60 inches from the ground).
- Page 12 STEP 5 - Option 1: Installing on a wood stud wall You’ll need Lag bolt (U) (2) Template (D) Drill Wall plate (A) Edge-to edge Lag bolt washer stud finder (T) (2) 7/32” wood drill bit 1/2” socket Pencil Tape wrench Level Notes:...
- Page 13 RF-HTMT15 Align the wall plate template (D) at the height you determined in the previous step and make sure that it is level. Tape the wall plate template to the wall, then use a pencil to mark the lag bolt hole locations (2) on the stud center. Remove the wall plate template.
- Page 14 Align the wall plate (A) with the pilot holes, insert the lag bolts (U) through the lag washers (T) and the holes in the wall plate, then tighten the lag bolts only until they are firm against the wall plate. CAUTION: Avoid potential injuries or property damage! DO NOT over-tighten the lag bolts (U).
- Page 15 RF-HTMT15 Align the wall plate template (D) at the height you determined in the previous step and make sure that it is level. Tape the wall plate template to the wall, then use a pencil to mark the lag bolt hole locations (3). Remove the wall plate template.
- Page 16 Insert the concrete wall anchors* into the pilot holes and use a hammer to make sure that the anchors are flush with the concrete surface. Align the wall plate (A) with the anchors, insert the lag bolts (U) through the lag washers (T) and the holes in the wall plate, then tighten the lag bolts only until they are firm against the wall plate.
- Page 17 RF-HTMT15 STEP 6 - Attaching your TV to the wall mount • Holding the TV with the top of the screen tilted toward the wall, slide the upper notches of the right and left TV brackets (B and C) over the upper lip of the wall plate (A). Then, gently lower the TV until the lock engages the lower lip of the wall plate (A).
- Page 18 STEP 7 - Adjusting the tilt angle You’ll need Level Phillips screwdriver Adjust the swivel tension knob by hand, then adjust the tilt angle by gripping the top and bottom of the TV and manually moving the TV to the angle you want. When you are done adjusting the tilt tension, re-tighten the knob, but do not over-tighten.
- Page 19 RF-HTMT15 Removing the TV from the wall mount • Pull the latches down to unlock the TV from the wall mount, then pull the bottom of the TV out from the wall and lift it up and off the wall plate.
-
Page 20: Lifetime Limited Warranty
Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges. This warranty lasts as long as you own your Rocketfish Product during the Warranty Period. - Page 21 FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS. ROCKETFISH PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND...
- Page 22 Part # 6907-302065 www.rocketfishproducts.com 1-800-620-2790 (U.S. and Canada) ROCKETFISH is a trademark of Best Buy and its affiliated companies. Registered in some countries. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2022 Best Buy. All rights reserved.
