Galvin Engineering Flowmatic TZ-FLOWSENC24B Product Installation

Product Installation Guidelines
®
Flowmatic Stainless Steel Retro Fit Bluetooth
Face Plate 24V AC, Suits Enw. Sensor
PRODUCT CODE:
TZ-FLOWSENC24B
-
SPECIFICATIONS
−
Flowmatic ® automatic concealed wall assembly is an aesthetically pleasing, single temperature
water control unit, which can be used for hand basins, sinks, or any application to initiate a
controlled flow of water.
−
The multiple time cycle option is able to be adjusted on site which provides the facility manager the
flexibility of adjusting to suit user requirements.
−
Sensor circuit boards are supplied standard with a lacquer finish to limit the damage that may be caused
by moisture
−
Built in capacitors and easy fit electrical filters help suppress external noise and provide a
continuous, reliable delivery of water.
−
1.5mm thick stainless steel face plate with hand activation sensor. It is designed to be mounted
flush into the wall/trough.
−
®
Flowmatic Electronic controller is a 24V AC electronic control system allowing the Flowmatic
Automatic Concealed Sensor Assembly to be used in various applications. Controller is pre-
programmed and ready to use. The solenoid will open for a specific time once the sensor will
detect hands movement. The standard program can be modified to suits individual needs. To
modify the operation settings a compatible Android device with Bluetooth is required.
TECHNICAL DATA
Power Supply
(Required – not supplied)
Sensor
Controller
Finish (user)
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without
notice.
© Galvin Engineering Pty Ltd
Type
Input
Output
Type
Activation
Input Voltage
Program type
Connections
Version 1, 8 September 2021, Page 1 of 10
Version 1, 8 September 2021, Page 1 of 5
Transformer
240V - 50Hz 30VA
24V - 917mA Max 22VA
Infra-Red
Hand movement
24V AC
Flowmatic
Terminal Plug 2 way 3.81mm or
Molex 2.36mm, 3 Way, Female
Stainless Steel
®
