Xytronic LF-3500 Instruction Manual

High frequency soldering station

Advertisement

Quick Links

INSTRUCTION MANUAL
FOR
LF-3500
High Frequency
Soldering Station

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LF-3500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Xytronic LF-3500

  • Page 1 INSTRUCTION MANUAL LF-3500 High Frequency Soldering Station...
  • Page 2: Key Features

    INTRODUCTION Thank you for purchasing Xytronic’s high heat capacity soldering station – the best solution for your soldering equipment needs especially for lead free applications! We believe that you will be more than satisfied with many features and the versatility of your new soldering station.
  • Page 3: Product Description

    working time, which minimize concern about the influence of heat on components and tip life ◆ ENERGY SAVER: If the station is set to the auto sleep function setting mode , after the station has been idle for more than 20 minutes, this new feature will automatically knick in.
  • Page 4 The LF-3500 incorporates electronic circuitry which enables the user to alter tip temperature from 100 to480℃without changing tips or heating elements. Also, with digital display readout and pressing keys on the front panel get clear vision and comfortable setting. The temperature is maintained within +/-3℃ of its operating temperature by a thermocouple sensor placed in the head of the heating element, allowing the tip to rest against the sensor.
  • Page 5 Rear side ○ 8 AC Power cord in-let ○ 9 Fuse ○ 10 Earth Jack Fig. 1 Soldering iron introduction Sensor: Ahead of the tip , greatly sense the temperature. Heating element :With the Tip: separated part, can high-frequency heating ,get the be easily replace.
  • Page 6: Specifications

    SPECIFICATIONS: Model LF-3500 Input 220-240Vac 50Hz 100-120Vac 60Hz Output 36Vac/150W Fuse (Slow type) 100℃~480℃ Temperature Range Temperature Correction +99℃~-99℃ Range 100℃ No Password Default Set Temperature correction value“00” Degrees Centigrade 111x158x137mm(W x H x D) Figure Dimension Weight (Unit only) 2.2g...
  • Page 7: Function Introduction

    To comply with safety standards, the power lead must only be replaced by authorized technicians as special purpose tools are required. DO NOT MODIFY THE LF-3500. Caution: Soldering irons operate at high temperatures and can easily burn people or objects.
  • Page 8 number as “010”, the unit will enter the modes selection procedure, otherwise, the unit will be back from the current mode automatically. 2. After the unit enters the Modes selection, the LED will display “F-0”and flash. Press “▲”or “▼” key to select modes. If the user doesn’t press “▲” or “▼” key within 15 seconds or press “SET”...
  • Page 9 Please note the manufacturer original design will keep in “Free” status without setting “Sleep” mode. 6.Wake-up method ① Temperature Down Suspend: If the unit is set in Sleep mode function, after 20min idleness, the system will enter the sleep mode automatically, the temperature will go down to 100℃...
  • Page 10: Maintenance

    4. Apply solder to the joint, not the tip when soldering. The flux is naturally caustic and thus will eat away the tip. 5. Never clean the tip with a file or abrasive materials. 6. Do not use fluxes which contain chloride or acid. Use only rosin or resin activated fluxes.
  • Page 11 INTERCHANGEABLE TIPS...
