3.5. Changing a tyre/tube/wheels
We recommend to put the E-Bike on a service stand to perform a wheel assembly and disassembly. It is the safest, both for the E-Bike
and the user, as well as the easiest way to perform any kind of replacement and maintenance procedures.
It is still possible to perform tyre or wheel changes with the E-Bike upside down but protection should be added on the display to
prevent damage and care must be taken to not tip over the E-Bike.
3.5.1. Removing/Fitting the Front Wheel
Please refer to the assembly videos provided on Modmo's YouTube channel for further detail on the removal and fitting of the front wheel.
Step 1. Unplug the motor cable located on the side of the front
The wheels
electric motor.
are easier to
remove if
you put the
bike into a
service
stand or
place it
upside
down.
Note: If you
place the bike
upside down,
please cover
Step 3. Insert the MOD Axle Nut tool into the MOD Axle Nut and
the display to
loosen the bolt so it can turn freely without completely removing
protect it
it and there is visible space between the nut and the fork/frame.
from damage.
One hand should hold the front wheel to prevent it from slipping
down when loosening the MOD Axle Nuts.
Note: If the
front wheel
has been
removed, do
not press the
brake lever.
Step 2. Locate the MOD Axle Nut tool in the rear Modular
mount and attach it to the 16mm spanner provided in the
tool box.
Step 4. Carefully remove the front wheel from the dropout.
