  • Page 1 Spedal NaviCam User Manual Smart Car Stereo CL796W/CL797 025C3316-EN...

  • Page 2: Table Of Contents

    Content 1. Safety Guidelines.........01 3. Functions And Settings......05 1.1 Warnings............01 3.1 Home Screen..........05 1.2 Precautions..........01 3.2 Apple CarPlay..........07 3.3 Android Auto..........14 2. User Manual...........02 3.4 Apple AirPlay..........19 2.1 Package List..........02 3.5 DVR.............22 2.2 Product Introduction.........02 3.6 Playback............23 2.3 Suction Bracket Installation....03 3.7 Settings.............24 2.4 Device Installation........03 3.7.1 System Settings........24...

  • Page 3: Safety Guidelines

    Scan the QR code, select the corresponding model, accessories by yourself. and view the User Manual. · Do not install, use or place this product within the reach of https://spedal.cc/html/support/download/dashcam.html children under 16 years of age. For any questions please contact support@spedaltech.com...

  • Page 4: User Manual

    2. User Manual 2.1 Package List 2.2 Product Introduction ◆ Device ◆ Suction Bracket ◆ Power Cable Screen ◆ Audio Cable ◆ Quick Guide ◆ Dashboard Pad Mounting Disk USB-C Port TF Card Slot ◆ Camera （Optional）◆ Camera Cable ◆ USB Type-C Cable （Optional）...

  • Page 5: Suction Bracket Installation

    2.3 Suction Bracket Installation 1.Align the suction bracket clips with the holes on the back of the device and push them up to secure the bracket. 2.Thoroughly clean and dry the car dashboard surface, remove dust or debris, and make sure the surface is flat. 3.Remove the 3M adhesive release paper from the dashboard pad mounting disk and adhere it to a clean instrument panel surface.

  • Page 6: Audio Cable Installation

    2.5 Audio Cable Installation 2.7 Camera Installation-1 （ Optional） 1. Insert the audio cable into the 1. Tear off the protective film of the camera lens. car AUX port, and connect the other end to the AUX OUT 2. Peel off the 3M adhesive port of the device.

  • Page 7: Functions And Settings

    3. Features And Settings 3.1 Home Screen Video Lock Status Lock Unlock 04/20/2023 12:30:24 Android Auto Status Android Auto CarPlay AirPlay Green: Connected CarPlay Status Green: Connected Audio Out FM Status Green: Connected Speaker Status Recording Status TF Card Status Red Flash: Recording On Normal Not Inserted...
  • Page 8 Android Auto Apple CarPlay Apple AirPlay Android Auto Apple CarPlay Apple AirPlay Apple CarPlay Apple AirPlay not Android Auto not not connected. connected. connected. A p p l e A i r P l a y A p p l e C a r P l a y A n d r o i d A u t o connected to the connected to the...

  • Page 9: Apple Carplay

    3.2 Apple CarPlay 1.Go to Settings on your 3.2.1 Apple CarPlay Wireless Connection iPhone, turn on “Bluetooth” and “Wi-Fi”. Settings Note: Sign in to your iPhone The iPhone version that supports wireless CarPlay requires the following: Airplane Mode ·iPhone is running iOS 9 or higher. (such as Wi-Fi >...
  • Page 10 "Bluetooth Pairing Request" Bluetooth device starting <Settings Bluetooth <Settings Bluetooth will pop up on your phone. with "Spedal-*****" Bluetooth Bluetooth Select "Pair" to successfully from the list of “Other Now discoverable as “X6”. Now discoverable as “X6”. MY DEVICES...
  • Page 11 Not connected Not Now Use CarPlay 3.If you want to switch to Android Auto or Other DEVICES Spedal-****** AirPlay, you need to turn off Bluetooth and Wi-Fi on your phone to disconnect the Apple ****** CarPlay connection mode.
  • Page 12 3.2.2 Apple CarPlay Audio Out 2.1 Go to Settings on your Click " " on the home screen to enter the Audio Out. iPhone > Bluetooth，turn 1. Built-in Speaker on the “Bluetooth”. Settings The sound is played from the speaker of the Sign in to your iPhone device.
  • Page 13 Bluetooth Bluetooth. Now discoverable as “X6”. Now discoverable as “X6”. MY DEVICES MY DEVICES Bluetooth Pairing Request Not connected Not connected ****** ****** ****** Not connected Not connected Pair ****** ****** Cancel Other DEVICES Other DEVICES Car****** Spedal-****** ****** ******...
  • Page 14 3. AUX Connection Note: Connect to the car through an AUX Please confirm if your car supports AUX IN cable, and the sound will play from the and note that the location of the AUX may car's speakers. vary depending on the car model. Please 1.Insert the audio cable into the car AUX port, and consult your manufacturer for more details.
  • Page 15 Refer to [3.1 Home Screen] FM Transmitter 04/20/2023 12:30:24 89.2 Please operate the volume adjustment 89.2 FM Frequency on the mobile phone/car side TUNING +/- 0.1 103.0 0.00 0.00 10:25 89.2MHz Scale&Pointer 103.0 Save Current Frequency Status Saved 10:25 89.2MHz Save Current Frequency Status To Be Saved...

  • Page 16: Android Auto

    3.3 Android Auto 3.3.1 Android Auto Connect With USB Type-C Cable （Optional） Note: What you need： 1.An Android phone with Android 8.0 (Oreo) and up, an active data plan, and the latest version of the Android Auto app. Android 2.An original USB cable. Before you connect your phone for the first time, turn on your car.
  • Page 17 3.3.2 Android Auto Wireless Connect 1.Go to Settings on your Note： phone, turn on "Blue- What you need： tooth" and "Wi-Fi". Settings A compatible Android phone with an active data plan, 5 GHz Wi-Fi support, and the ******* latest version of the Android Auto app. Profile Security Apps Wireless projection is compatible with these Connections...
  • Page 18 3.After entering the “Blue- 2.Click on "Bluetooth" to tooth” menu, click "Pair enter the Bluetooth new devices" to search for search page. Connections Connected devices > > new Bluetooth devices. Wi-Fi Pair new devices Previously connected devices Bluetooth ****** NFC and Cast ****** ****** Flight mode...
  • Page 19 Available devices DEVICES" Bluetooth Spedal-*****", click "Pair" Spedal- ****** Spedal- ****** Pairing... devices. (as shown below), and Pair with Spedal- ***** ? ****** ****** wait for the Bluetooth Allow access to your contacts ****** ****** and call history pairing to complete. After...
  • Page 20 Refer to [3.1 Home Screen] Bluetooth 04/20/2023 12:30:24 Click " " on the home screen to enter the Audio Out. Please operate the Device discoverable as “Spedal-*****” volume adjustment 1. Built-in Speaker on the mobile Saved devices Available devices phone/car side.

  • Page 21: Apple Airplay

    3.4.1 Apple AirPlay Wileless Connect The same as the page12--3.2.2--3.Aux Connection. 1.Go to Settings on your 4. FM Transmitter iPhone > Wi-Fi Settings The same as the page12--3.2.2--4.FM Transmitter. Sign in to your iPhone Airplane Mode Wi-Fi Spedal-*** > Bluetooth > Mobile Data...
  • Page 22 2.Select the WiFi network 3.Swipe down from the top with the name starting of the iPhone screen to with "Spedal-*****" and access the Control Center Cancel Enter Password Join connect to it. Enter the menu, then tap "Screen Password 12345678 password, the default Mirroring".
  • Page 23 3.4.2 Apple AirPlay Audio Out 4.Click on NaviCam to complete Screen Mirroring. Click " " on the home screen to enter the Audio Out. 1. Built-in Speaker Screen Mirroring The sound is played from the speaker of the device. NaviCam 2.

  • Page 24: Dvr

    3.5 DVR Start / Stop Sound Recording Click " " on the home screen to enter the DVR. Start Stop Refer to [3.1 Home Screen] Lock / Unlock Current Video 03:25 1080P 04/20/2023 12:30:24 Lock Unlock Take Picture Back To Home Screen Playback Setting White：Carplay mode or Android Auto mode...

  • Page 25: Playback

    3.6 Playback Click " " on the home screen to enter the play- back mode, where you can play, lock, unlock, delete Current Page Nr. / Total Page Nr. 1/126 videos or pictures. Locked Picture File Refer to [3.1 Home Screen] Unlocked Picture File Playback 1/126...

  • Page 26: Settings

    3.7 Settings Click " " on the home screen to enter the Settings mode. 3.7.1 System Settings 3.7.2 Video Settings Screen saver Record resolution Set the time for the screen to automatically turn Set the resolution of the video,720P,1080P,2K off. 10 seconds, 30 seconds, 1 minute or off can can be selected.
