- Page 1 Spedal NaviCam User Manual Portable Car Stereo with Dashcam CL518 034C3825-EN...
-
Page 2: Safety Guidelines
User Manual. · Do not disassemble, repair or modify this product and accessories by yourself. https://spedal.cc/html/support/ download/navicam.html · Do not install, use or place this product within the reach of children under 16 years of age. -
Page 3: Package List
2. User Manual 2.1 Package List ◆ Device ◆ Dash Mount ◆ Power Cable ◆ Audio Cable ◆ Quick Guide ◆ Camera （Optional） ◆ Rear Camera （Optional） Note D o n o t u s e c a b l e s a n d components that are not original. -
Page 4: Product Illustration
2.2 Product Illustration Turn off/on screen Screen TYPE-C AV-IN AUX Audio TF Card Slot Camera Interface Power Interface... - Page 5 2.3 Device bracket installation(Dashboard) 1. Thoroughly clean and dry the surface of the car dashboard, removing any dust or debris and ensuring a smooth surface. 2. Peel off the protective film from the bottom adhesive of the device bracket. 3. Stick the device onto the appropriate position on the dashboard. 4.
- Page 6 2.4 Device bracket installation （Windshield） 1. Select an appropriate installation position and wipe the installation position thoroughly. 2. Remove the protective film at the bottom of the suction cup. 3. Secure the suction cups to the windshield. 4. Turn the locking knob on the sucker support to secure the sucker. 5.
-
Page 7: Device Installation
2.5 Device Installation Insert the power cable into the car cigarette lighter, and connect the other end to the power interface of the device. Note Depending on the vehicle, TYPE-C AV-IN t h e c i g a r e t t e l i g h t e r socket may be located in a different position. -
Page 8: Camera Installation
2.7 TF Card Installation （Optional） · Insert the TF card into the TF card slot. · The self-provided TF card should meet the TYPE-C AV-IN following require m ents: Class 10 or above, the capacity does not exceed 128GB. 2.8 Camera Installation 2.8.1 Windshield （Optional）... - Page 9 2.8.2 Rear Windshield （Optional） 1. Thread the camera's wire through the hole on the adhesive bracket, and following the direction of the arrow, tighten and rotate the bracket with the camera, ensuring they are securely fastened together. 2.Peel off the protective film from the adhesive bracket, and attach the bracket to the vehicle's rear windshield.
- Page 10 2.8.4 Rear Camera （Optional） 1. Connect the rear camera to the Rear camera cable, and insert the other end into the rear camera port (AV-IN) of the device; 2. Use the rear camera bracket to fix the rear camera above the license plate; 3.
-
Page 11: Features And Settings
3. Features and Settings 3.1 Home Screen Apple CarPlay Android Auto Wifi Video Audio output 15:18 Playback Setting 2023-07-28 Fri... - Page 12 Bluetooth Status Blue : Connected Homepage Adjusting screen brightness Recording On Adjusting speaker audio output volume Apple CarPlay Mode Android Auto Mode DVR Mode System time Wi-Fi Video Audio Output TF card inserted TF card not inserted Apple CarPlay Connected Video Playback Mode Setting Android Auto Connected...
-
Page 13: Apple Carplay
Bluetooth > 1. Go to Settings on your iPhone, turn on “Bluetooth” Other DEVICES Spedal-****** and “Wi-Fi” Mobile Data ****** 2.Enter the “Bluetooth ”menu and select the Bluetooth device starting with "Spedal-*****" from the list of “Other DEVICES” Bluetooth devices. - Page 14 The sound is played from the speaker of the device. Cancel Not connected Not Now Use CarPlay Other DEVICES Other DEVICES Spedal-****** Spedal-****** 2. Bluetooth ****** ****** In CarPlay/Android Auto mode, the phone is directly connected to the car's Bluetooth (if the phone has...
- Page 15 Note Not connected Pair ****** Cancel Please confirm if your car supports AUX IN and note that Other DEVICES Spedal-****** the location of the AUX may vary depending on the car ****** model. Please consult your manufacturer for more details.
-
Page 16: Android Auto
4. FM Transmitter 98.5 FM Frequency Connect through FM to play sound through TUNING +/- 0.1 your car's audio system. 4.1 Adjust the car FM to a frequency that is not occupied by Scale&Pointer the broadcast, and adjust the device FM to the same frequency;... - Page 17 ****** 5.Wait for about 20 seconds, a prompt box will pop up on ****** the phone with "Pair with Spedal-*****", click "Pair" (as shown below), and wait for the Bluetooth pairing to complete. After the Android Auto connection is complet- ed, it will automatically enter the Android Auto mode.
- Page 18 3.3.2 Andorid Auto Audio Out Settings Connections > Click“ ”on the home screen to enter the Audio Out. Wi-Fi ******* Profile Security Apps Bluetooth 1. Built-in Speaker Connections NFC and Cast Wi-Fi,Bluetooth,Flight mode The sound is played from the speaker of the device. Sound and vibration Flight mode Sound mode,Ringtone...
- Page 19 Pair Cancel long, please be patient. the device's Wi-Fi as prompted. The Wi-Fi name is "Spedal-******" and the default password is "12345678". 3. The connection is successful, and the phone and device enter the DVR mode. 3. AUX Connection My Camera...
- Page 20 3.4 DVR Recording in progress Recording stopped Click " " on the home screen to enter the DVR. Unlocked video 10:07 Locked video Thur, 17 Aug 2023 Take Picture Back to homepage Audio output Stop sound recording 10:07 Date and Time Start sound recording Thur, 17 Aug 2023...
- Page 21 3.5 Playback Playback Click " " on the main screen to enter Play- back Mode, where you can play, lock, unlock, and Play the next video delete videos or pictures. 00:00:00/00:00:00 Playback progress / Video duration Video Full screen playback Photo Locked video Previous Menu...
- Page 22 3.6 Setting Camera Click " " on the main screen to enter the Camera format settings mode. Set the camera format. It can be set to 720P, 720N, 1080P or 1080N. Display Record Resolution 2.5K Auto-dimming Set the video resolution. It can be set to 720P, Enable or disable eye care mode, you can set 1080P or 2.5K.
- Page 23 Tip sound Reverse line calibration You can turn on or off the alert tone. Turn reversing line calibration on or off. Storage info Date and Time Check the remaining storage space of the TF card. Set the date and time, as well as the date format. Format Clear Connections Delete all data on the TF card.
- Page 24 Download manuals of other languages from our homepage. Laden Sie Handbücher in anderen Sprachen von unserer Homepage herunter. Téléchargez des manuels dans d'autres langues depuis notre page d'accueil. Descargue manuales en otros idiomas desde nuestra página de inicio.
