- Page 1 User Manual Smart Car Stereo CL811/CL811Pro 039C3C09-EN...
-
Page 2: Safety Guidelines
Scan the QR code, select the corresponding model, and view the User Manual. · Do not disassemble, repair or modify this product and accessories https://spedal.cc/html/support/download/navicam.html by yourself. · Do not install, use or place this product within the reach of children For any questions please contact support@spedaltech.com... -
Page 3: Package List
2. User Guide 2.2 Product Introduction 2.1 Package List ◆ Device ◆ Power Cable ◆ Audio Cable ◆ Suction Bracket Turn off/on screen ◆ Dash Mount ◆ Camera ◆ Camera Screen （Optional） （Optional） （Optional） ◆ Camera Cable ◆ Quick Guide ◆... - Page 4 2.3 Suction Bracket Installation 2.4 Dash Mount installation(Optional) 1.Align the suction bracket clips with the holes on the back of the device 1. Thoroughly clean and dry the surface of the car dashboard, and push them up to secure the bracket. removing any dust or debris and ensuring a smooth surface.
-
Page 5: Device Installation
2.5 Device Installation Insert the power cable into the car cigarette lighter, and connect the other end to the power interface of the device. Type-C AV-IN Note Note Please confirm if your car supports AUX IN and note that the location of the AUX may vary depending on the car model. - Page 6 2.8 Camera Installation （Optional） 2.8.2 Inside Rear Windshield(Optional) 1. Thread the camera's wire through the hole on the adhesive bracket, 2.8.1 Windshield(Optional) and following the direction of the arrow, tighten and rotate the brack- 1. Thread the camera's wire through the hole on the adhesive et with the camera, ensuring they are securely fastened together.
- Page 7 2.Following the direction of the arrow, tighten and rotate the bracket with the camera, ensuring they are securely fastened together. 3.Attach the bracket to the headrest support pole. Type-C AV-IN 4.Secure the bracket using the screws provided in the accessories. 5.Use the camera extension cable to connect the camera to the device.
-
Page 8: Features And Settings
1. Go to Settings on your iPhone, turn on “Bluetooth” and “Wi-Fi” CarPlay connected to the device. AirPlay connected to the device. 2.Enter the “Bluetooth ”menu and select the Bluetooth device starting with "Spedal-*****" from the list of “Other DEVICES” Miracast Android Auto Bluetooth devices. - Page 9 Cancel paired with the car's Bluetooth before, there is no need to Bluetooth > repeat the connection operation). Other DEVICES Other DEVICES Spedal-****** Spedal-****** Mobile Data 2.1 Go to Settings on your iPhone > Bluetooth，turn on the ****** ****** “Bluetooth”.
- Page 10 3. AUX Connection 4.1 Adjust the car FM to a frequency that is not occupied by the broadcast, and adjust the device FM to the same frequency; for Connect to the car through an AUX cable, and the sound will example, adjust the car FM to 91.0MHz (if not occupied), and then play from the car's speakers.
-
Page 11: Android Auto
Pair Cancel 4.Select the Bluetooth device starting with "Spedal-*****" from the list of "Other DEVICES" Bluetooth devices. 5.Wait for about 20 seconds, a prompt box will pop up on the phone with "Pair with Spedal-*****", click "Pair" (as shown Note below), and wait for the Bluetooth pairing to complete. - Page 12 Pair new devices Pair new devices > > Available devices Available devices 2.1 Go to Settings on your phone > Bluetooth， turn on the “Bluetooth”. Spedal- ****** Car-****** Pairing... ****** Pair with Car-****** ? ****** 2.2 Enter Bluetooth search page.
-
Page 13: Apple Airplay
1. Go to Settings on your iPhone > Wi-Fi Screen Mirroring SmartScreen 2. Select the Wi-Fi network with the name starting with "Spedal-****" and connect to it. Enter the password, the default password is “88888888”. Screen Mirroring 3. Swipe down from the top of the iPhone screen to access the Control Center menu, then tap "Screen Mirroring". - Page 14 3.5 Miracast 3.6 DVR Click " " on the home screen to enter the DVR. Click " " on the home screen to enter the Miracast. 2023-12-20 14:37:38 01:37 1. Go to Settings on your phone, turn on "Wi-Fi". 2. Swipe down from the top of the phone screen to access the Control Center menu, then tap "Screen Cast".
- Page 15 3.7 Playback Click " " on the home screen to enter the Playback mode. Return to the superior directory Delete videos or photos Front ordinary video(0) Front photos(0) Front emergency video(0) Video or photo file name and Choose any video or photo directory preview image，click to play Select all videos or photos Rear ordinary video(0)
- Page 16 Sound Settings Language Adjust device volume, enable or disable key sound, and Set the language displayed by enable or disable power on/off sound. the system.English,日本語 App download ,Русский язык,Français,Pol- ski,Español,ViệtName,Português, Scan the QR code displayed on the prompt box with your , 한국어,Deutsch, phone to download the RoadCam App.
- Page 17 Download manuals of other languages from our homepage. Laden Sie Handbücher in anderen Sprachen von unserer Homepage herunter. Téléchargez des manuels dans d'autres langues depuis notre page d'accueil. Descargue manuales en otros idiomas desde nuestra página de inicio.
