4. Basic Installation & Configuration

4.1 Connecting the Hardware

•
Make sure that your USB devices are switched off and that the Server's Power Adapter is
disconnected.
•
Connect the USB devices to the USB port with the USB cables.
•
Connect the MFP Server to your modem or wireless router with an Ethernet cable.
•
Turn on the USB device and make sure it's ready to use.
•
Connect the Power Adapter to the MFP Server. The power indicator will light up and the
indicator will flash. When the Link indicator lights up, the Server is correctly connected to
the network. When the USB indicator stops flashing, the Server is ready to use.

4.2 Assigning an IP Address to the Server

Note：
Before starting to search the MFP server, please ensure all Firewall applications are turned off (or
unblock the Control center software in your Firewall settings.

4.2.1 Preliminary

If you have a DHCP server in your network, your MFP Server will receive an IP address
•
automatically. The IP address will then appear in the Control Center or on the configuration
report that you printed earlier. If your DHCP server does not give an IP address to the MFP
Server, the MFP Server will use the Factory IP address: 192.168.0.220.
If you are not working in a DHCP network, you need to manually set the Server's IP
•
address.
To do this, please connect the MFP server directly to your PC. Change the IP settings on
•
your computer to match the range of the MFP server Factory IP address (192.168.0.220).
For example, temporarily change the IP-address on your computer to '192.168.0.200'.

4.2.2 Manual Setting for Server's IP address

Press Start -> Control Panel. Then select "Network and Internet Connections" and
•
click "Network Connections".
Double click the "Network Connection" icon. Under the "This connection uses the following
•
items", select the "Internet Protocol (TCP/IP)". And then click "Properties" button.
