EN
OPERATING
INSTRUCTIONS
DISHWASHER
HS6130
www.gorenje.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS6130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hisense HS6130

Summary of Contents for Hisense HS6130

  • Page 1 OPERATING INSTRUCTIONS DISHWASHER HS6130 www.gorenje.com...

  • Page 2: Table Of Contents

    Contents Your dishwasher ..................Safety instructions ..................Before washing for the first time ............... Loading the dishwasher ................Using the dishwasher ................Settings ..................... Care and cleaning ..................Troubleshooting ..................Installation ....................Service ...................... Information for test institute ............... Technical information ................Your dishwasher 1.

  • Page 3: Safety Instructions

    Safety instructions General Installation • Read the operating instructions and See the chapter Installation. keep them in a safe place! Child safety • Never use the dishwasher for any Children must be watched. Do not allow purpose other than that specified in children to use or play with the these operating instructions.

  • Page 4: Before Washing For The First Time

    Before washing for the first time • Supports made from untreated wood. Checking water hardness • Protective plastic made from In order to achieve good dishwashing results, the dishwasher needs soft water polyethylene (PE). (water with low mineral content). Hard Disposal water leaves a white coating on dishes The dishwasher is manufactured and...
  • Page 5 achieve a better dishwashing result with Set the Water hardness clear and spotless dishes. Chapter Settings describes how to adjust the water softener. Press to open Top up with salt 1. Open the rinse aid compartment lid. 2. Carefully top up with rinse aid to the Salt compartment lid level marked max.

  • Page 6: Loading The Dishwasher

    Loading the dishwasher Greener dishwashing • Angle dishes with hollows, such as cups, so that the rinse water will run off. • Do not rinse under running water. This is also important for plastic items. Simply scrape off large food particles •...
  • Page 7 Upper basket Place glasses, cups, bowls, side plates and saucers in the upper basket. All dirty surfaces should face inwards and downwards! Wine glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right (if fitted). Foldable tines The foldable tines can be folded up or down to make it easier to load pots, bowls...

  • Page 8: Using The Dishwasher

    Using the dishwasher Add detergent catch inwards before adjusting their position. Press to open 1. Prewash detergent compartment 2. Main wash detergent compartment Detergent is added according to water hardness. Follow the instructions on the detergent packaging. This dishwasher is fitted with a water softener, so use detergent and rinse aid doses suitable for soft water.
  • Page 9 detergent will not be released properly if PROGRAM - Select a the lid is tight and will not open correctly. programme NOTE! Select a programme to suit the type of Dishwasher tablets are not dishes and how dirty they are. Eco wash recommended for short programmes is always pre-selected.
  • Page 10 NOTE! Eco wash The dishwasher door must not be blocked when set to open automatically. This programme is intended for cleaning This can disrupt door lock functionality. normally dirty dishes and is the most effective programme in terms of combined energy and water consumption.
  • Page 11 updated after the water for the final rinse Once the programme has finished has been heated. Once the programme has finished, "End" appears on the display. This may differ somewhat from time to time depending on the temperature of the The dishwasher switches off automatically water supply, the amount of dishes, the after the programme ends.

  • Page 13: Settings

    Settings Open the settings menu: First, open the door. Turn off the machine. Press and hold the main power switch until the display lights up. Within 10 seconds: - press the Programme selector and the option button for Speed wash. The display shows the settings menu (current setting and its currently set value).
  • Page 14 Settings Options Water hardness 2:00 - 2:09 Adjusting the water softener. Select a setting depending on the hardness of the water supply. It is important that this setting is correct! German French wa- Recom- water ter hard- mended hardness ness scale setting scale 0-5°dH...
  • Page 15 Settings Options 3:00 (Off) You can activate this setting when (3-in-1/all-in-one 3:01 (On) using 3-in-1/ All-in-one detergent. The detergent) dishwashing programmes automatically adapt to provide the best possible dishwashing and drying results every time. If this setting is activated there is no need to add rinse aid since this option disables rinse aid dispensing.

  • Page 16: Care And Cleaning

    Care and cleaning WARNING! Top up with rinse aid In order to avoid rust stains a When the rinse aid needs topping up, the dishwashing programme must be started above symbol lights on the display. immediately after adding salt. Press to open Never pour dishwasher detergent into the salt compartment.
  • Page 17 2. Lift the filter straight up using the Lower spray arm handle. Free the coarse filter to clean • Pull the lower spray arm straight up to the fine filter. release it. 3. Refit in reverse order. Check that the edges seal properly when refitting the fine filter.
  • Page 18 • Call the service department. The dishwasher tub The dishwasher tub is made of stainless steel and is kept clean through normal use. Limescale deposits If you have hard water, limescale deposits Drainage pump stop may build up in the dishwasher. If this happens, run the Intensive wash programme with two tablespoons of citric NOTE!

  • Page 19: Troubleshooting

    Troubleshooting Type of fault on the dis- Action play Overfilling Clear the drainage pump. See the chapter Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem”...
  • Page 20 Problem Possible causes Action Cannot close door. The baskets are not Check that the baskets are correctly positioned. correctly positioned horizontally. Check that the dishes are not blocking the baskets from sliding properly into place. The door lock does not click Check the door lock.
  • Page 21 Problem Possible causes Action The dishwasher does not The door is not properly Check. start. closed. You have opened the Close the door and wait. dishwasher to add more After a while, the dishes while a programme dishwasher continues the is in progress.
  • Page 22 Problem Possible causes Action The dishes are not clean. The spray arms do not Remove the arms and clean rotate. them. Check that the dishes are not blocking the spray arms. Spray arm holes or bearings Clean the spray arms. See blocked.
  • Page 23 Problem Possible causes Action Spots on stainless steel or Some foodstuffs, such as Rinse off these types of silver. mustard, mayonnaise, foodstuffs if not starting the lemon, vinegar, salt and dishwasher immediately. dressings, can mark Use the Rinse programme. stainless steel if left for too long.
  • Page 24 Problem Possible causes Action Spots left after washing. Lipstick and tea can be Use a detergent with a difficult to wash off. bleaching agent. Detergent residue in the The detergent compartment The detergent compartment detergent compartment after was damp when adding must be dry when adding dishwashing.
  • Page 25 Problem Possible causes Action Bad odour in dishwasher. Dirt around the seals and in Clean with washing-up corners. brush and low foaming cleaner. Low temperature Run a programme with a programmes have been higher temperature about selected for a prolonged once a month.

  • Page 26: Installation

    Installation [mm] 1214 Nominal dimensions. Actual measurements may vary. Safety instructions WARNING! • Connections to electricity, water and Turn off the water supply when installing drainage must be performed by a the dishwasher! qualified professional. The plug must be disconnected or power •...
  • Page 27 Lean the dishwasher forwards a little Placing the dishwasher and adjust the rear foot with the screw The dishwasher is intended for at the front of the dishwasher. Turn freestanding installation, but can also be clockwise to lower or anticlockwise to installed under a worktop.
  • Page 28 No part of the drainage hose may be more Attach the plinth than 950 mm above the bottom of the (Packed inside the dishwasher.) dishwasher. The hose must not be routed directly to a floor drain or the like. In such cases, the hose can act as a siphon and empty the dishwasher.
  • Page 29 settle for a while. Check that all NOTE! connections are watertight. Change of electrical cables as well as repairs and maintenance relating to Connection to cold water supply safety or performance must be carried Connect the dishwasher to the cold water out by the manufacturer’s service agent supply if the building is heated using oil, or someone with similar professional...

  • Page 30: Service

    Service Information for test institute Read the chapter Troubleshooting before Request test institute information via contacting the service department. e-mail Provide the details on the serial number dishwashers@appliance-development.com. plate in all contact. Include the article The request should include the details on number (1) and the serial number (2).
  • Page 31 Your notes...

  • Page 32: Technical Information

    Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 Hisense Model designation: HS6130 Number of standard place settings: Energy efficiency class: A+++ Annual energy consumption(AE 245 kWh per year Energy consumption of the standard cleaning cycle(E 0.86 kWh...
