WIRING DIAGRAMS (cont):

KB & KC System Wiring
MAGNETIC LOCK
WIRING METHOD:
(Normally Closed contact)
LOCK
POWER
+ +
-
Use Brown & Yellow wires
when connecting to Maglock.
KC-DAR
NOTE: The door release contacts are rated at 12V AC, 400mA. The RY-24L should be used in any application where the
strike or maglock has a higher voltage or draws more current. Otherwise, internal damage to the KB/KC monitor could result.
A1
KB-DAR
A2
ELECTRIC STRIKE
WIRING METHOD:
(Normally Open contact)
To (-) of
power supply
Blk
-
Brn
COM
Org
Yel
N/C
A1
A2
ELECTRIC STRIKE
WIRING METHOD:
(Normally Open contact)
Brn
Org
Yel
LOCK
POWER
Red
Connect Red
to Orange
lead of Master
Blk
Red
Brn
COM
Org
N/O
Yel
LOCK
POWER
Master
KB-3MRD
1A1 B1
1A2 B2
2A1
2A2
3A1
3A2
+
Blk
-
CN11
Red
Org
Yel
KC-1GRD
KC-1MRD
1A1 B1
1A2 B2
+
-
Yel
S
Org
S
PS-2420UL
+
-
Connect
YELLOW
wire of CN11
directly to +
on unit.
PS-2420UL
+
-
Connect
YELLOW
wire of CN11
directly to +
on unit.
