- Page 1 INVERTER GENERATOR OPERATOR’S MANUAL Part No: TM523-4500 Ver: 1.1 TO PREVENT SERIOUS INJURY OR DAMAGE TO YOUR GENERATOR, READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS BEFORE USE www.itmtools.com.au...
-
Page 2: Table Of Contents
TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL TABLE OF CONTENTS Warranty ........................Product Specifications ..................... General Safety Rules For Operation ............... Usage ........................Control Function ....................... Pre-Operation ......................Operation ......................... Maintenance ......................Troubleshooting ....................... LIMITED WARRANTY Industrial Tool & Machinery Sales (hereinafter referred to as ITMS) will, within twelve (12) months from the original date of purchase, repair or replace any goods found to be defective in materials or workmanship. -
Page 3: Product Specifications
ITM inverter generators also have the added feature of parallel connection capability, this means that when you join any two ITM inverter generators together in parallel connection, you get the full combined rated power output whenever you need it. Keep your options open and add power as and when your demand changes. -
Page 4: General Safety Rules For Operation
TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL GENERAL SAFETY RULES FOR OPERATION DANGER Never use the generator in a location that is wet or damp. Never expose the generator to rain, snow, water spray or standing water while in use. Protect the generator from all hazardous weather conditions. - Page 5 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL ADDITIONAL SAFETY RULES FOR GENERATORS Do not force the generator. Use the correct generator for your application. The correct generator will do the job better and safer at the rate for which it was designed.
-
Page 6: Usage
TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL USAGE WARNING NEVER exceed the rated wattage capacity of your generator. OVERLOADING may cause SERIOUS DAMAGE to the generator and attached electrical devices and may result in fire. Your generator MUST BE SIZED PROPERLY to provide both the running and starting (surge) wattage of the devices you will be powering. - Page 7 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
-
Page 8: Control Function
Control Function TM523-4500 INVERTER GENERATOR Inverter Generator Owner's Manual OPERATOR’S MANUAL CONTROL FUNCTION Start / Stop switch &\ CD Engine switch "OFF". lgnition circuit is switched off. Fuel is switched off. The engine will not run. ® Engine switch ® "ON". - Page 9 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
- Page 10 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
- Page 11 The generator setting output frequency TM523-4500 INVERTER GENERATOR can't change if it operates. OPERATOR’S MANUAL DC protector The DC protector turns to "OFF" automatically when electric device being connected to the generator is operating above the rated flows. To use this equipment again, turn on the DC protector by pressing the "ON"...
- Page 12 When the electric device is earthed, always the generator must be TM523-4500 INVERTER GENERATOR earthed. OPERATOR’S MANUAL Parallel Operation Outlets This is the terminal G)for connecting special cables for parallel running of two generators. The parallel running requires two generators and the special cables.
-
Page 13: Pre-Operation
TM523-4500 INVERTER GENERATOR Pre-oparation Pre-oparation OPERATOR’S MANUAL Inverter Generator Owner's Manual Inverter Generator Owner's Manual Pre-oparation Inverter Generator Owner's Manual Pre-oparation Pre-oparation Pre-oparation I 1 ······ p re-op _ eration checks shoufd"be made each" " fime N OT I CE Pre-operation checks should be made each time prior I 1 ······... - Page 14 Pre-oparation Inverter Generator Owner's Manual TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL Engine Oil The generator has been shipped without engine oil. Do not start the engine till fill with the sufficient engine oil. Do not tilt the generator when adding engine. This could result in overfilling and damage to the engine.
-
Page 15: Operation
TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL Operation Inverter Generator Owner's Manual Operation N ever operate the engine in a closed area or it may cause NOTICE unconsciousness and death within a short time. Operate the engine in a well ventilated area. The generator has been shipped without engine oil. - Page 16 Operation TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL Inverter Generator Owner's Manual Electric start Turn the engine switch on the control panel to ON . And press it to START or turn key right if it's electrical start state, then generator unit can be started.
- Page 17 TM523-4500 INVERTER GENERATOR Operation OPERATOR’S MANUAL Inverter Generator Owner's Manual STOPPING THE ENGINE Release the load. TIP: Turn off any electric devices. 1. Disconnect any electric devices. 2. Turn the ESC to "OFF" CD. 3. Turn the Start / Stop switch to "OFF"·...
- Page 18 Operation TM523-4500 INVERTER GENERATOR Inverter Generator Owner's Manual OPERATOR’S MANUAL ALTERNATING CURRENT (AC) CONNECTION Be sure any electric devices are turned off before plugging A.WARNING them in. • Be sure all electric devices including the lines and plug NOTICE connections are in good condition before connection to the generator.
- Page 19 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
- Page 20 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL Operation Inverter Generator Owner's Manual AC Parallel Operation Applications TIP: • Make sure that it is in good working order. A faulty appliance or power cord can create a potential for electrical shock. • If an appliance begins to operate abnormally, becomes sluggish, or stops suddenly, turn if off immediately.
- Page 21 Application Range TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL Inverter Generator Owner's Manual When using the generator, make sure the total load is within rated output of a generator. Otherwise, generator damage may occur. , . . . a ._ tlEI· �,..�...
- Page 22 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
- Page 23 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
-
Page 24: Maintenance
Maintenance TM523-4500 INVERTER GENERATOR Inverter Generator Owner's Manual OPERATOR’S MANUAL SPARK PLUG INSPECTION The spark plug is important engine components, which should be checked periodically. 1. Unscrew but unloosen the screw CD , and take off the left exterior cover@. - Page 25 Maintenance TM523-4500 INVERTER GENERATOR Inverter Generator Owner's Manual OPERATOR’S MANUAL CARBURETOR ADJUSTMENT The carburetor is a vital part of the engine. Adjusting should be left to a dealer with the professional knowledge, specialized date, and equipment to do so properly.
- Page 26 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
- Page 27 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
- Page 28 Maintenance TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL Inverter Generator Owner's Manual 1. Unscrew 6 bolts G) , and take off shutter®· 2. Remove the muffler screen @ , and remove the bolt © 3. Clean the carbon on the muffler screen by wire brush.
- Page 29 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL Storage and Transportation Inverter Generator Owner's Manual Storage and Transportation Long term storage of your machine will require some preventive procedures to guard against deterioration. DRAIN THE FUEL 1. Turn the Start / Stop switch to "OFF".
-
Page 30: Troubleshooting
Troubleshooting TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL Inverter Generator Owner's Manual Troubleshooting ENGINE CAN'T START 1. Fuel systems • No petrol in the fire chamber. • No fuel in the fuel tank ... add fuel. • Fuel in tank. • Clogged fuel filter ..Clean fuel filter. - Page 31 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
- Page 32 TM523-4500 INVERTER GENERATOR OPERATOR’S MANUAL www.itmtools.com.au...
