Number Connector
4x DisplayPort 1.2 for external screens
2x RJ 45
2x USB 3.0 (type A)
2x USB 2.0 (type A)
1x Audio In (mini jack 3.5mm)
1x Audio Out (mini jack 3.5mm)
2 x DMX512-A OUT (5pin XLR female)
1 x DMX512-A IN (5pin XLR male)
1 x MIDI IN (5pin DIN female)
1 x MIDI OUT (5pin DIN female)
1 x LTC – Linear Time Code IN (3pin XLR female)
1 x GPI – General Purpose Input (D-SUB DE9 female – remote control)
1x IEC connector C14
1 x LED desk light (4pin XLR female)
For technical specifications see Technical Data in the grandMA3 Quick Manual onPC command wing XT.
© 2022 MA Lighting Technology GmbH - Dachdeckerstr. 16 - 97297 Waldbüttelbrunn - Germany
Phone +49 5251 688865-30 - support@malighting.com - www.malighting.com
AC 100 - 240V 50/60 Hz
