CONFIGURATION SETTINGS

TIME DELAY CONFIGURATION
1. Read through the Time Delay Settings list and note the number of the
desired time delay setting (e.g., default is 4 = 10 minutes)
2. Press and release the unit's pushbutton twice, then wait 2 seconds.
The White LED will blink back the number of the current setting
3. At any time after blink back starts, enter number of new setting
(from Time Delay Settings table on right)
4. New setting is saved after White LED blinks new number back 3 times.
If Blue LED double flashes at any time, start process over

OPERATION MODE CONFIGURATION

To disable the operation of the photocell (in equipped units), use the following procedure:
1. Press and release the unit's pushbutton 3 times, then wait 2 seconds. The White LED
will blink back the number of the current setting.
3. At any time after blink back starts, enter number of new setting from table on right
(e.g., 2 for OCCUPANCY - ON/OFF) from OPERATIONAL MODES table.
4. New setting is saved after White LED blinks back new number 3 times. If Blue LED
double flashes at any time, an error condition exists and process must be repeated.
MICROPHONE
Dual technology sensors prevent non-occupant sounds from resetting the time delay
by dynamically reducing the microphones sensitivity at specific frequencies. In some
environments, decreasing the sensitivity across all frequencies so that lights go off
sooner, may be preferred. A unit's microphone can also be disabled (effectively changing
sensor to a PIR only version).
TO CHANGE MICROPHONE SETTINGS:
1. Press unit's pushbutton 6 times, then wait two seconds. The White LED will blink back
the number of current setting (from table on right).
2. At any time after blink back starts, enter number of new setting by pressing the button
equal times to choice from table.
3. New setting will be saved after White LED blinks back new number 3 times. If Blue
LED double flashes at any time, start process over.
LED INDICATION
By default, the sensor blinks its White LED whenever it detects PIR motion. A unit with
dual technology will also blink the LED white when it acoustically detects occupancy. The
intensity of this LED can be increased or disabled. Additionally, the LED can be enabled to
blink white for only PIR events and blue for an acoustic event.
TO CHANGE LED INDICATION SETTINGS:
1. Press unit's pushbutton 7 times, then wait two seconds. The White LED will blink back
the number of current setting (from table on right).
2. At any time after blink back starts, enter new setting by pressing the button equal
times to numbered choices.
3. New setting will be saved after White LED blinks back new number 3 times. If Blue
LED double flashes at any time, start process over.
FUNCTION #2 - TIME DELAY SETTINGS
SETTING # DESCRIPTION
1 Test Mode**
2 30 sec
3 5 min
4 10 min [Default]
5 15 min
6 20 min
7 30 min
FUNCTION #3 - OPERATIONAL MODES
SETTING # DESCRIPTION
2 Occupancy - On/Off
Occupancy + Ambient Light Override
3
(Photocell)
FUNCTION #6 - MICROPHONE
SETTING # DESCRIPTION
2 Normal Operation [Default]
3 Reduced Sensitivity
4 Disabled
SETTING # DESCRIPTION
2 White LED for all occupancy, normal brightness [Default]
3 White LED for all occupancy, increased brightness
4 Disable LED
5 White LED for PIR, Blue for Acoustic, normal brightness
6 White LED for PIR, Blue for Acoustic, increased brightness
** 5 SEC TIME DELAY, EXPIRES AFTER 10 MIN
MODEL # NOTES
Default for SWX-20x-2 & SWX-22x-2
Default for SWX-21x-2 & SWX-23x-2
