Metra Electronics AXXESS AXDSPX-HD2 Installation Instructions Manual

Hide thumbs

INTERFACE COMPONENTS

• AXDSP-X circuit board

• AXDSPX-HD2 harness (with gaskets)

• AXDSPX-HD2 enclosure

• Case

• Cap (with O-ring)

AxxessInterfaces.com

Harley Davidson DSP

Package with Water

2014-Up

Resistant Enclosure

INTERFACE FEATURES

• Water resistant plug-n-play harness for the AXDSP-X

• AXDSP-X included

• Water resistant enclosure with zip tie mounts included

• Amplifier, if equipped, does not need to be retained

• All wiring will be done at the radio location

• Micro-B USB updatable

AXDSPX-HD2

I N S T A L L A T I O N I N S T R U C T I O N S

TABLE OF CONTENTS

Connections ............................................................2

Installation ......................................................... 3-4

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

Apple App Store

Google Play Store

iOS 12.1 or higher

ATTENTION:

With the key out of the

ignition, disconnect the negative battery

terminal before installing this product. Ensure

that all installation connections, especially the

air bag indicator lights, are plugged in before

reconnecting the battery or cycling the ignition

to test this product.

NOTE: Refer also to the instructions included

with the aftermarket radio.

REV. 2/9/23 INSTAXDSPX-HD2

Table of Contents

Need help?

Do you have a question about the AXXESS AXDSPX-HD2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Metra Electronics AXXESS AXDSPX-HD2

Page 2 CONNECTIONS Factory Radio Zip-tie Mounts Case White / Front Left + Green / Rear Left + White/Black / Front Left - Green/Black / Rear Left - AXDSP-X Gray / Front Right + Purple / Rear Right + Circuit Board Gray/Black Front Right - Purple/Black / Rear Right - Cap (with O-ring) Locking clip shown...
Page 3 INSTALLATION Attention! Harley Davidson radios come pre-programmed with a preset EQ that cannot be changed without flashing the radio. Only an authorized Harley Davidson Dealer can flash the radio and flatten the factory EQ curve. Ask the Dealer to flash the radio to a flat EQ curve. Without performing this task, the AX-DSP will be distorted and not sound very good.
Page 4 INSTALLATION (CONT’D) 7. Download and install the AXDSP-X app from the Google Play Store or Apple App Store. 8. Open the app and follow the instructions on the Bluetooth Connection tab to pair the mobile device to the AXDSP-X. (Figure B) 9. Scroll to the Configuration tab then select the vehicle type. Press the Lock Down button to save the configuration.
Page 5 REV. 2/9/23 INSTAXDSPX-HD2...
Page 7 REV. 2/9/23 INSTAXDSPX-HD2...
Page 8 Log onto www.installerinstitute.edu or call 386-672-5771 for more information and take steps toward a better tomorrow. Metra recommends MECP certified technicians AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 2/9/23 INSTAXDSPX-HD2...
