NISSAN BLUETOOTH/INFORMATION DISPLAY
RETENTION INTERFACE
Installation Instructions
* READ IMPORTANT WARNING ON PAGE 1
BEFORE ATTEMPTING ANY INSTALLATION
When installing an aftermarket radio into select
Nissan vehicles, the Bluetooth features (if equipped)
are lost.The driver information display is also lost
which it is controlled by the factory radio.The NIRD-
01 is designed for use in 2007-08 Nissan Maxima
and 2007-08 Nissan Sentra vehicles to retain the
factory Bluetooth features (if equipped) and informa-
tion display.
Nissan Maxima/Nissan Sentra 2007-2008
• NIRD-01 Interface
• Wired keypad
• Pocket insert keypad mount for 99-7421
• Pocket insert keypad mount for 99-7422
• 1 interface to vehicle/display harness
• 1 interface to radio harness
• 1 interface to radio/vehicle/keypad harness
• Two sided tape
1-800-221-0932
© COPYRIGHT 2007 METRA ELECTRONICS CORPORATION
NIRD-01
Applications
Interface Components
www.metraonline.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metra Electronics Axxess NIRD-01
Summary of Contents for Metra Electronics Axxess NIRD-01
-
Page 1: Installation Instructions
• Pocket insert keypad mount for 99-7421 • Pocket insert keypad mount for 99-7422 • 1 interface to vehicle/display harness • 1 interface to radio harness • 1 interface to radio/vehicle/keypad harness • Two sided tape 1-800-221-0932 www.metraonline.com © COPYRIGHT 2007 METRA ELECTRONICS CORPORATION... - Page 2 NIRD-01 INTERFACE COMPONENTS AXXESS NIRD-01 INTERFACE -TOP AND BOTTOM VIEW WIRED KEYPAD POCKET INSERT KEYPAD MOUNT FOR 99-7421 AND 99-7422 INTERFACE TO RADIO/VEHICLE/KEYPAD HARNESS INTERFACE TO VEHICLE DISPLAY HARNESS 14 WAY HARNESS INTERFACE TO RADIO HARNESS-14 WAY TWO-SIDED TAPE...
- Page 3 NIRD-01 * IMPORTANT WARNING THIS PRODUCT INCLUDES INSTRUCTIONS FOR INSTALLATION WHICH MUST BE CAREFULLY FOLLOWED. THE INSTRUCTIONS ARE WORDED IN SUCH A MANNER TO ASSUME THAT THE INSTALLER IS CAPABLE OF COMPLETING THESE TYPE OF ELECTRONIC INSTALLATIONS. IF YOU ARE UNCLEAR AS TO WHAT YOU ARE INSTRUCTED TO DO OR BELIEVE THAT YOU DO NOT UNDERSTAND THE INSTRUCTIONS SO AS TO PROPERLY AND SAFELY COMPLETE THE INSTALLATION YOU SHOULD CONSULT A TECHNICIAN WHO DOES HAVE THIS KNOWLEDGE AND UNDERSTANDING.
- Page 4 NIRD-01 16-pin interface to radio/vehicle/keypad harness The 16-pin interface to radio/vehicle/keypad harness has three connectors on it along with wires to connect to the aftermarket radio. • The White 20 way connector plugs into the main vehicle harness. • The Black 16 way connector plugs into the NIRD-01 interface. •...
- Page 5 NIRD-01 6. 14-pin interface to radio harness. NOTE: If the connections are made in a different order than shown, the vehicle display may not operate correctly. If this occurs, unplug the 16-pin harness then re-connect. 7. Find an appropriate location inside the dash behind the radio to place the interface. 8.
- Page 6 NIRD-01 PERSONALIZED SCREEN NOTE: There are 10 characters including spaces available. To customize the My Nissan screen with your own personal message, follow these steps: 1. Using the Trip Info button, select the My Nissan screen option. 2. Press and hold the Clock Display button for three seconds Set Display will now appear on the display. 3.
- Page 7 NIRD-01 NOTES...
- Page 8 NIRD-01 INSTRUCTIONS 1-800-221-0932 www.metraonline.com REV. 12/04/07 © COPYRIGHT 2007 METRA ELECTRONICS CORPORATION INSTNIRD-01...
