Digital Watchdog DWC-PMB-WLW Quick Start Manual

Pole mount bracket

1. Accessories & Dimension

Please check if all the camera and accessories are included in the package.

Camera Mounting Screws

NOTE:

Download all your support materials and tools in one place.

Go to: http://www.digital-watchdog.com/resources

Search your product by entering the part number in the 'Search by Product' search bar. Results

for applicable part numbers will populate automatically based on the part number you enter.

MOUNTING HOLES #5

Click 'Search'. All supported materials, including manuals

DWC-BLJUNC-W and

and quick start guide (QSGs) will appear in the results.

DWC-PBJUNC junction

boxes for bullet cameras

Pole mount bracket for

DWC-PMB-WLW

139.5

200

WHAT'S IN THE BOX

MOUNT POINT 1

MOUNT POINT 3, 4

102mm x 142mm

ø121mm

MOUNT POINT 5

MOUNT POINT 2

ø78mm

105mm x 110mm

Mount Screw 4ea

Quick Start Guide

Table of Contents

Need help?

Do you have a question about the DWC-PMB-WLW and is the answer not in the manual?

Page 1 Quick Start Guide Pole mount bracket for DWC-PMB-WLW 1. Accessories & Dimension Please check if all the camera and accessories are included in the package. 139.5 nual carefully. WHAT’S IN THE BOX MOUNT POINT 1 MOUNT POINT 3, 4 102mm x 142mm ø121mm...
Page 2 Quick Start Guide INSTALLATION NOTE: The pole bracket requires a steel band to secure the mount to the pole. It is not included with the accessory at this time and should be purchased separately at a hardware store. The recommended dimensions for the steel band are: Length: 18.5”...
