Ceiling mounting bracket for white analog PTZ cameras
1x Teflon tape
4x O-ring
1x hex Allen wrench (2.5)
3x plastic anchors (6pi)
3x tapping screws, PH (6x35)
NOTE:
Download all your support materials and tools in one place.
1.
Go to: http://www.digital-watchdog.com/resources
2.
Search your product by entering the part number in the 'Search by Product' search bar. Results
for applicable part numbers will populate automatically based on the part number you enter.
Click 'Search'. All supported materials, including manuals
3.
and quick start guide (QSGs) will appear in the results.
Tel: +1 (866) 446-3595 / (813) 888-9555
Technical Support Hours: 9:00AM – 8:00PM EST, Monday through Friday
DWC-P220CMW
WHAT'S IN THE BOX
2x set screws, no head (M5x5)
2x machine screws, BH (UNC #8-32 8L)
4x machine screws, PH (M6x9)
7x machine screws, PH (M6x12)
1x quick setup guide
Quick Start Guide
digital-watchdog.com
Advertisement
Table of Contents
Related Manuals for Digital Watchdog DWC-P220CMW
Summary of Contents for Digital Watchdog DWC-P220CMW
- Page 1 Quick Start Guide Ceiling mounting bracket for white analog PTZ cameras DWC-P220CMW WHAT’S IN THE BOX 1x Teflon tape 2x set screws, no head (M5x5) 4x O-ring 2x machine screws, BH (UNC #8-32 8L) 1x hex Allen wrench (2.5) 4x machine screws, PH (M6x9)
- Page 2 1.65" (42mm) 3. Cable passing through 1.65" (42mm) the wall with the junction box (Attention to the plate side) Cable Junction Copyright © Digital Watchdog. All rights reserved. Rev Date: 01/20 Specifications and pricing are subject to change without notice.
