- Page 1 PBZ Assembly Instruction Manual Kit: Power wash and jug rinse Model: A311K Manufactured by PBZ LLC A Paul B Zimmerman Inc. Company www.CropCareEquipment.com Form: A311KAM_REV-A...
-
Page 2: Installation Time
A311K Assembly Instructions Subject The purpose of this document is to show the procedure for installing a powerwash and jug rinse unit onto a sprayer. Installation Time: • Approximately 4 hours Recommended Tools • 3/8” socket or wrench • 9/16” socket or wrench •... - Page 3 A311K Assembly Instructions A311K Kit Contents Ref# Qty. Part Number Description 40 FT 1008 Hose, EPDM Rubber 1/2" 300 PSI 21010010 Nozzle, Garden Hose Pistol Grip Plastic 2101830 Garden hose washer, red rubber 38027 Cap, Nozzle Tip/barb 11/16-16 UNF Poly 3A100 Adapter, Hose 1"...
- Page 4 A311K Assembly Instructions A311K Kit Contents Ref# Qty. Part Number Description 3EL1412 Elbow, Hose 90° 1/4" MPT x 1/2" HB 6806052 Hose Clamp, 1/2" - 29/32" SS 6816052 Hose Clamp, 11/16" - 1-1/2" SS 6820052 Hose Clamp, 3/4" - 1-3/4" SS 8007-594-838 Pump, 12V w/Switch &...
- Page 5 A311K Assembly Instructions Step 1 • Bolt pump and filter mounting bracket (Item 1) to the eduction mount (a). Ref# Qty. Part Number Description T1029 Powerwash pump and filter mount CB38*34G5 Bolt, Carriage 3/8-16 x 3/4" Gr 5 FN38 Nut, Flange 3/8-16...
- Page 6 A311K Assembly Instructions Step 2 • Install fittings onto the filter (Figure 1). Use Teflon tape and pipe sealant on all threads. • Install the filter onto the pump and filter mounting bracket (a) installed in Step 1 (Figure 2). Figure 1 Figure 2 Ref#...
- Page 7 A311K Assembly Instructions Step 3 • Install fittings onto pump as shown. Use Teflon tape and pipe sealant on all threads. • NOTE: The elbow is on the inlet side of the pump and the tee is on the outlet side. Ref# Qty.
- Page 8 A311K Assembly Instructions Step 4 • Install the pump assembly (a) from the previous step onto the pump and filter mounting bracket (b). Ref# Qty. Part Number Description FW10 Washer, Flat #10 SS MR1024*114 Screw, Machine Rd Hd 10-24 x 1-1/4" NNC1024 Nut, Lock Nylon 10-24 SS...
- Page 9 A311K Assembly Instructions Step 5 • Drill a 3/4” hole into the side of the eduction tank (a) for the jug rinse. • NOTE: The side of the tank closest to the hitch of the sprayer. The hole will be 4 1/2” from the top of the tank and 5 1/2” from the corner.
- Page 10 A311K Assembly Instructions Step 6 • Assemble fittings for the jug rinse nozzle as shown. Use Teflon tape and pipe sealant on all threads. Ref# Qty. Part Number Description 38027 Cap, Nozzle Tip/barb 11/16-16 UNF Poly CP12094NYB Body, Nozzle Type-1/4 Inlet-NYB Nylon DC56NY Core, TeeJet Nylon Black DVP6...
- Page 11 A311K Assembly Instructions Step 7 • Install assembled jug rinse fittings (a) from previous step into eduction tank. • NOTE: The gasket (Item 1) is installed on the inside of the tank. Ref# Qty. Part Number Description 2101830 Garden hose washer, red rubber...
- Page 12 A311K Assembly Instructions Step 8 • Install ball valve (Item 2) and elbow (Item 1) onto the jug rinse nozzle bulkhead fitting. Use Teflon tape and pipe sealant on all threads. • Apply the jug rinse label (Item 3) to the eduction tank. •...
- Page 13 A311K Assembly Instructions Step 9 • Assemble pipe fittings as shown (Figure 1). Use Teflon tape and pipe sealant on all threads. • NOTE: If installing on a 200, 300, or 400 gallon trailer, use 3A100 instead of Item 1. •...
- Page 14 A311K Assembly Instructions Step 10 • Assemble garden hose nozzle and hose barb fitting. Ref# Qty. Part Number Description 21010010 Nozzle, Garden Hose Pistol Grip Plastic 3D3412 Fitting, Garden Hose 3/4" MGHT x 1/2" HB Poly...
- Page 15 A311K Assembly Instructions Step 11 • Install the hose hanger bracket (Item 1) as shown. • On a 200, 300, or 400 gallon trailer the hose hanger bracket (Item 1) is installed on the safety rinse tank pan (a) Figure 1. Use items 1, 2, and 3.
- Page 16 A311K Assembly Instructions Step 12 • Install hoses onto hose barb fittings. Ref# Qty. Part Number Description 40 FT 1008 Hose, EPDM Rubber 1/2" 300 PSI 6806052 Hose Clamp, 1/2" - 29/32" SS...
- Page 17 A311K Assembly Instructions Step 13 The pump harness needs to be hooked up to the sprayer controls. On electric controls with the CropCare Wiring Harness the pump wiring harness is connected to terminals inside of a junction box. • Plug the wiring extension harness (Item 1) into the pump plug and then route the wiring harness extension (Item 1) to the junction box.
