- Page 1 Owner's Manual Picking Assistant Model PA1400 PBZ LLC | 50 Wood Corner Rd | Lititz PA 17543 www.CropCareEquipment.com | (717) 738-7365 A Paul B Zimmerman Inc. Company Form: 1400OM Rev. Date 08/13...
-
Page 3: Table Of Contents
® CropCare would like to thank you for choosing to purchase one of our picking assistants. We appreciate your business and want to fill all of your sprayer and equipment needs. We also desire to provide you with the technical support and needed parts that will allow ®... -
Page 4: Safety Precautions
Safety Precautions General Guidelines Every year many unnecessary accidents occur due to improper equipment handling and a disregard for safety precautions. You, the operator, can avoid accidents by observing the precautions in this section. • The operator should be a responsible adult. not allow persons to operate this machine until they have displayed a thorough understanding of the safety precautions and operational use! -
Page 5: Operating Instructions
Operating Instructions Moving the Picking Assistant The Picking Assistant can be moved either by hand or towed by an ATV or tractor. Be sure that both motors (a) are in the neutral position, as shown (Figure 1) before attempting to move the picking assistant. - Page 6 Operating Instructions Operator Adjustments ... continued After making a height adjustment, tie up any extra wire with the bungee tie so the wire cannot become entangled in the drive wheel. Repeat this process for all three wheels. Note: On hillsides the rear wheel heights should be separately adjusted to level the machine.
-
Page 7: Picking Assistant Operation
Operating Instructions Picking Assistant Operation Check to be sure the battery on the picking assistant is charged and ready for use. Press the battery check button (a) on the switch box, and read the gauge (b) above it to assure the battery is charged (Figure 7). Make sure the motor assembly (a) is not in the neutral position and that the pull-pin is properly locked into one of the operating position holes (b) as shown (Figure 8). -
Page 8: Assembly The Canopy
Operating Instructions Assembling the Canopy 29” When transporting the picking assistant be sure to remove the canopy as it cannot withstand speeds over 15 MPH. Follow 2” these instructions to properly reassemble the canopy upon arrival. Install the canopy frame brace (a). First, place a 15/16” shaft collar (b) 2”... -
Page 9: Maintenance Instructions
Maintenance Instructions Routine Maintenance It is very important to perform routine maintenance on your picking assistant before and after each use. Good maintenance practices will help to guard against any unnecessary machine breakdowns or accidents. It is recommended to perform a visual and physical Always rinse off any mud and dirt from the motor gears inspection for any worn parts, loose bolts, or other and tires after every use. -
Page 10: Battery Storage
Maintenance Instructions Battery Maintenance ... continued If using a regular battery charger, or a deep cycle charger be useless and may damage the battery and shorten its on the manual setting, do not leave a battery on the charger life. If the battery won’t come up to full charge, replace it. for more than 48 hours to avoid damaging the battery by 10. -
Page 11: Wiring Diagram
Wiring Diagram PA1450 Wiring Harness Schematic Test Foot switch Switch Black Voltmeter Black Black Wire Nut Wire Nut Control Switch Fuse Yellow (+) (20 amp) Plug Plug Power Plug Plug Plug Plug Supply Part of motor Black (-) Part of motor PA1451 (pig-tail harness) Rear Front... -
Page 12: Breakdowns & Parts Lists
Breakdowns & Parts Lists Picking Assistant Breakdown Base Frame, Knee Pad, and Foot Rest to knee pad... -
Page 13: Base Frame, Knee Pad, And Foot Rest Parts List
Breakdowns & Parts Lists Picking Assistant Parts List Base Frame, Knee Pad, and Foot Rest Ref # Qty. Part Number Description CB38*134G5 Carriage bolt, 3/8-16 x 1 3/4" CB38*1G5 Carriage bolt, 3/8-16 x 1" CB38*314G5 Carriage bolt, 3/8-16 x 3 1/4" CB38*4G5 Carriage bolt, 3/8-16 x 4"... -
Page 14: Battery And Wiring Assembly, Chest Pad, And Canopy Support Breakdown
Breakdowns & Parts Lists Picking Assistant Breakdown Battery and Wiring Assembly, Chest Pad, and Canopy Supports foot switch to rear motor to front motor... -
Page 15: Battery And Wiring Assembly, Chest Pad, And Canopy Tube Parts List
Breakdowns & Parts Lists Picking Assistant Parts List Battery and wiring assembly, chest pad, and canopy tubes Ref # Qty. Part Number Description B03189 Battery box CB1024*12 Carriage bolt, #10-24 x 1/2" CB38*314G5 Carriage bolt, 3/8-16 x 3 1/4" CB38*3G5 Carriage bolt, 3/8-16 x 3"... -
Page 16: Wheel, Motor, Head Rest, And Picking Tray Breakdown
Breakdowns & Parts Lists Picking Assistant Breakdown Wheels and Motors, Head Rest, and Picking Tray... -
Page 17: Wheel, Motor, Head Rest, And Picking Tray Parts List
Breakdowns & Parts Lists Picking Assistant Parts List Wheels and Motors, Head Rest, and Picking Tray Ref # Qty. Part Number Description PA1419A Wheel adjustment tube PA1420 Head rest brace PA1425A Motor drive wheel PA1427 Head rest tube PA1434 Picking tray tube PA1435 Picking tray shield PA1436... -
Page 18: Canopy Assembly And Storage Tray Breakdown
Breakdowns & Parts Lists Picking Assistant Breakdown Canopy Assembly and Storage Tray Detail B Detail B (Assembled, canopy hidden) Detail A Detail A (Assembled) -
Page 19: Canopy Assembly And Storage Tray Parts List
Breakdowns & Parts Lists Picking Assistant Parts List Canopy Assembly and Storage Tray Ref # Qty. Part Number Description 0938P Shaft collar 15/16" BS08 Ball bungee, 8" CB38*2G5 Carriage bolt, 3/8-16 x 2" DE46 Decal CROP CARE DE57 Decal, picking assistant canopy FN38 Flange nut, 3/8-16 PA1430... -
Page 20: Pa1450 Wiring Harness Breakdown & Parts List
Breakdowns & Parts Lists PA1450 Wiring Harness Breakdown & Parts List For ref # 8 For ref # 11 For ref # 2 To battery To rear motor To front motor Ref # Qty. Part Number Description E664 PVC junction box, 6” x 6” x 4” with cover DC7300131 Toggle switch, on-off-on DPDT PA1443... -
Page 21: Cropcare ® Limited Warranty
® CropCare Limited Warranty Picking Assistant: Model PA1400 Warranty Coverage ® ® CropCare hereby provides a Limited Two (2) Year Warranty on Picking Assistants, manufactured by CropCare . Picking Assistants ® manufactured by CropCare are warrantied against any manufacturer’s defects in any of the picking assistant’s components in the 24 months following the original date of purchase. -
Page 22: Notes
Notes... -
Page 23: Contact Us
Ordering Parts ® Please contact your authorized CropCare dealer to order replacement parts for your product. A brand of PBZ LLC A Paul B Zimmerman Inc. Company 50 Woodcorner Road Lititz PA 17543 (717) 738-7365 Fax (717) 738-7369...
