Summary of Contents for Chuphotic VENUS Ultimate S2.2 1KVA S

  • Page 1 User Manual True Online Double Conversion UPS VENUS Ultimate S2.2 VNU1-3KVA...
  • Page 2 All rights reserved. The information in this document is subject to change without notice. Publish statement Thank you for purchasing this series UPS. This series UPS is an intelligent, single phase in single phase out, high frequency online UPS designed by our R&D team who is with years of designing experiences on UPS.
  • Page 3: Table Of Contents

    Table of Contents 1.  Important Safety Warning ........................3  1-1  Transportation ..........................3  1-2  Preparation ........................... 3  1-3  Installation ............................ 3  1-4  Operation ............................4  1-5  Maintenance, service and faults ................... 4  1-6  Symbols used in this guide ..................... 5  2. ...
  • Page 4: Important Safety Warning

    1. Important Safety Warning Important safety instructions – Save these instructions Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully There exists dangerous voltage and high temperature inside the UPS.
  • Page 5: Operation

     When installing the equipment, it should ensure that the sum of the leakage current of the UPS and the connected devices does not exceed 3.5mA. 1-4 Operation  Do not disconnect the mains cable on the UPS system or the building wiring outlet (shockproof socket outlet) during operations since this would cancel the protective earthing of the UPS system and of all connected loads.
  • Page 6: Symbols Used In This Guide

     Please replace the fuse only with the same type and amperage in order to avoid fire hazards.  Do not dismantle the UPS system. 1-6 Symbols used in this guide WARNING! Riskofelectricshock CAUTION! Readthisinformationtoavoidequipmentdamage 2. Installationand setup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged.
  • Page 7: Real Panel View

    2-2 Real panel view...
  • Page 8: Setup The Ups

    2-3 Setup the UPS Step 1: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords.  For 208/220/230/240VAC models: The power cord is supplied in the UPS package. Step 2: UPS output connection ...
  • Page 9: Upsstartup And Turn Off

    2-4 UPSstartup and turn off  Startup operation (1) Turn on the UPS in line mode NOTE Verify that the total equipment ratings do not exceed the UPS capacity to prevent an overload alarm. a) Once mains power is plugged in, the UPS will charge the battery, at the moment, the LCD shows that the output voltage is 220, which means the UPS automatic ally tart the inverter.
  • Page 10 a) Press and hold the OFF key for more than half a second to turn off the UPS and inverter. b) After the UPS shutdown, the LEDs go out and there is no output. If output is needed, you can set bps “ON” onthe LCD setting menu. (1) Turn off the UPS by DC without mains power a) Press and hold the OFF key for more than half a second to turn off the UPS.
  • Page 11 The UPS is in Bypass mode. OnThe UPS is operating normally onbypassduring High Efficiency operation. Yellow OnThe UPS is in Battery mode. Yellow OnThe UPS is operating normally. Green NOTE When power on or startup , these indicators will turn on and off sequentially. NOTE On different operation modes , these indicators will indicate differently.
  • Page 12 Icon Functiondescription InputSourceInformation IndicatestheACinput. Indicateinputvoltage,inputfrequency,PVvoltage,batteryvoltage and Temp Configuration Program and Fault Information Indicatesthesettingprograms. Indicatesthewarningand faultcodes. Warning: flashingwithwarningcode. Fault: lighting withfaultcode OutputInformation Indicate output voltage, output frequency, load percent, load in VA, load in Watt and discharging current. Battery Information Indicates battery level by 0-24%, 25-49%, 50-74% and 75-100% in battery mode and charging status in line mode.
  • Page 13: Operations

    Indicatestheloadlevelby 0-24%,25-50%,50-74%and75-100%. 0%~25% 25%~50% 50%~75% 75%~100% Mode Operation Information Indicatesunitconnectstothemains. Indicatesloadissuppliedbyutilitypower . Indicatestheutilitychargercircuitis working. IndicatestheDC/ACinvertercircuitis working. Mute Operation Indicatesunitalarmisdisabled. 3. Operations 3-1 Button operation Function Button  Turn on the UPS: Press and hold ON button for at least 2 seconds to turn on the UPS. Confirmcurrentsettings:When the UPS ...
  • Page 14: Lcd Display

     Up key: Press this button to display previous UP Button selection in UPS setting mode.  Down key: Press this button to display next DOWN Button selection in UPS setting mode.  Setting mode: Press and hold this button for 5 UP + DOWN Button seconds to enter UPS setting mode.
  • Page 15 Load Environment Temperature UPS model. Firmware Version Alarm Code(Warming Message) All alarm codes are present when abnormal behavior(s) occur(s)
  • Page 16: Ups Setting

    3-3 UPS setting TheUPS has setting functions. This user settings can be done under any kind of UPS working mode. The setting will take effect under certain condition. Below table describes how to set the UPS. The setting functioniscontrolled by 4buttons (Up ,Down, ON/Enter,OFF/ESC): Up ▲+OFF/Down▼---goes into the setting page, ON/Enter ---- confirmthe settingsoptions Up ▲...
  • Page 17 Battery capacity setting Press Enterbutton to change the setting (Battery capacity range is 1-200Ah). Press UP button ▲ to select the previous setting. Press DOWN button ▼to select the next setting. Battery EOD voltae setting(Once) Press Enterbutton to change the setting (1.75/1.84/1.92).
  • Page 18: Operational Status And Mode(S)

    Mute setting Press Enter button to change thesetting(ON or OFF). Press UP button to select the previous setting. Press DOWN button to save and exit the setup. BYPASS enable/disable setting Press Enter button to change thesetting(ON or OFF). Press UP button ▲ to select the previous setting.
  • Page 19: Alarm Or Fault Reference Code

    3-5 Alarm or Fault reference code Event log UPS Alarm Warning Buzzer Rectifier Fault Beep continuously Fault LED lit Inverter fault(Including Inverter bridge Beep continuously Fault LED lit is shorted) Fan fault Beep continuously Fault LED lit Selftest fault Beep continuously Fault LED lit Battery Charger fault Beep continuously...
  • Page 20: Troubleshooting

    4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below and the Trouble Shooting Chart. Symptom Possible cause Remedy Check if input power cord The AC input power is not firmly connected to the connected well.
  • Page 21 Trouble Shooting Chart...
  • Page 22: Storage And Maintenance

    5. Storage and Maintenance  Operation The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case, please contact your dealer. Be sure to deliver the spent battery to a recycling facility or ship it to your dealer in the replacement battery packing material.
  • Page 23 Typical topologyoftheUPS NetworkManagement Relaycard (Options) Mini dry contact card is usedfoprovidingtheinterfaceforUPS peripheralmonitoring. Thecontact signalscanreflect runningstatus.The card isconnectedto peripheral monitoring devices terminal boardtofacilitatethe effective monitoring ofthereal-timestatusofUPS andtimely feedback thestatusto monitorwhen abnormal situation occurs(suchasUPSfailure, mains interruption,UPSbypassandect.). Itis installed in theintelligent slotofthe UPS. Therelaycard includes6 outputportsandone...
  • Page 24 (Options) Emergency Power-off (EPO) EPO is used to shut down the UPS from a distance. This feature can be used for shutting down the load and the UPS by thermal relay, for instance in the event of room overtemperature. When EPO is activated, the UPS shuts down the output and all its power converters immediately.
  • Page 25: Specification

    7. Specification MODEL 1KVA(S) 1KVA(H) 2KVA(S) 2KVA(H) 3KVA(S) 3KVA(H) PHASE Single phase with ground 3000VA /2400W/ 1000VA /800W/ 2000VA / Capacity (VA/Watts) 2700W/3000W 900W/1000W 1600W/1800W/2000W INPUT Nominal voltage 208/220/230/240VAC Operating Low line 176Vac±5% @100%-50% load; voltage transfer 110Vac±5% @50%-0% load; range (Ambient High line...
  • Page 26 Charge current 6A/12A 6A/12A 6A/12A SYSTEM FEATURES Line 105%~125%: UPS transfer to bypass after 1minute when the utility is normal Overload Mode 125%~130%: UPS transfer to bypass after 30 seconds when the utility is normal Battery >130%: UPS transfer to bypass immediately when the utility is normal Mode Short Circuit Hold Whole System...
  • Page 27 CHU-EN.UPS-56.MNL.VNU 1-3K S2.2.Rev1.00/2023...
