Chuphotic PLUTO PT800 User Manual

PLUTO
Specification
PT800 PT1000
Model
800/480 1000/600
Power Rate (VA/W)
Input Voltage
Output Voltage (AVR)
Output Voltage (Backup)
Battery Capacity
SLA 12V 9.4Ah x 1
Backup Time
Charging Time
Over / Under Voltage, Over Load, Short Circuit Protection
Protection System
Low Battery Shutdown Fault and Battery Replacement
Transfer Time
LED Display
Normal, Backup, Overload, Low Battery, Battery Replacement
Audible Alam
Backup mode, Low battery, Overload, Fault
Control Program
USB port & Cable with PowerManager software
AC Line Surge Protector
1,000,000W in 100
Tel / ADSL Surge TVSS
Standard Certification
ISO9001/14001, TIS.1291 1-2553, 2-2553, 3-2555, CE : IEC62040
Environment
-45
Dimensions (WxHxD) mm.
100x145x305
Weight kg.
6.2
OPERATION AND TEST THE UPS
Test UPS on battery back-up, switch off utility supply and observe 'backup indicator'
lights. Also your PC should continue to function normally.
1. Self-testing while Turn ON
Before turning on the UPS, the red/yellow/green led will be bright twice by turns.
then the UPS will be ready for operation.
2. Silence Function
In Battery Mode, shortly press the switch will enable or disable the buzzer.
But when UPS is low battery or overload, the buzzer can not be silenced.
3. Overload Protection
When UPS is overloaded while operating, which is not solved by the user in time,
it will cut off the output automatically after short time.
4. Autorun DC Start & AC Start
In DC mode, UPS discharges till battery run out and cut off, UPS autorun when
AC recover.
5. Low Battery shutdown
When the battery is about to be exhausted, UPS will shut down automatically to
protect battery's life.
6. Turn Off UPS
1. AC Normal UPS will cut off the output and goes to AC standby mode by
pressing the switch.
2. Backup Press the switch, the UPS will be turned off after a long beep.
7. Manual Self-testing
User need to check the UPS ready for operation, Press the botton two time quickly
then UPS self test, UPS transfer AC to Backup and Backup to AC.
TROUBLE SHOOTING
The trouble shooting chart covers most of the difficulties that you may encounter
under normal working conditions. If the UPS fails to operate properly, please review
the following steps before calling the service center.
1. Is the UPS plugged into a correct working outlet?
2. Is the line voltage within the rating specified?
3. Is the Fuse or Breaker / Circuit Protector on back panal open?
4. UPS has used long time > 2 Year that is short backup time or fault.
Please submit the following information when you call for service.
1. Model No. & Serial No.
2. Date of problem.
3. Full desciption of problem UPS.
PT1050 PT1200 PT1500
1050/630 1200/720 1500/900
220 Vac -34%, +32% (145-290 Vac)
220 Vac +10% (198-242 Vac)
220 Vac +3% (213.4-226.6 Vac)
SLA 12V 9.4Ah x 2
15-40min (Depened on Load)
Batt. Cap.90% in 3-6 Hours
4-6 msec
s
/ 160 Joules in 2 ms
µ
Tel / Fax / ADSL / RJ11 / RJ45
°
C / RH 0-90% Non condensing
123x155x335
7.3 10 11
UPS can not be turned
ON
Red LED continuous
bright with a beep every
8 seconds
Red LED continuous
bright with a beep every
1 seconds
Back-up time less than
12
specified
PT800 / PT1000
1. Power
5
2
5
PT800 / PT1000
1. AC Input
2. Auto reset CB
3. Outlets
TROUBLE SHOOTING CHART
UPS is not connecting
Please connect to AC
to AC and overloaded and reduce the load
Replace the Fuse or Reset
The input Fuse is burn the breaker, remove some
or Breaker is off
load and check if the load
is short-circuit or faulty
Please check the AC
AC Input voltage is too
Input Voltage
low
Please send to the
The UPS is failure
agency to repair
UPS suddenly turns to Save the data promptly
Battery mode in spite of and Shut down the
utility line present operating system
Backup time less than Close load and recharge
1 minute (low battery) immediately
Battery problem Replace the new battery
Use more load over Recharge the battery for
atleast 12 hours and
Battery is not fully
retest the backup time
charged
Use UPS > 2 year Replace the new battery
Charging unit fault Please send to the
agency to repair
Front Panel
1
2
3
4
PT1050 / PT1200 / PT1500
2. Overload 3. Normal
Rear Panel
5
4
3
3
OUTPUT UPS
1
10
2
PT1050 / PT1200 / PT1500
4. USB Port
5. Tel / Fax Surge
1
2
3
4
4. Backup
4
Smart µP Line Interactive
UPS with Stabilizer
CAUTION !
Risk of electrical shock.
Do not remove cover.
No user serviceable part Inside.
Refer servicing to qualified person
Refer manual for environmental.
