CMC Rescue 3D Instructions

CARRYING, MAINTENANCE & STORAGE
During all use, carrying, storage and transport keep the equipment away from acids, alkalis, rust and strong
chemicals. Do not expose the equipment to direct heat, flame or high temperatures.
Clean equipment using clean fresh water to remove any dust or debris. Do not use a pressure washer for cleaning.
If the equipment gets wet, remove excess moisture and allow to air dry at temperatures between 10° C and 30° C.
Lubricate moving parts as needed.
During storage and transport, protect the equipment from heat, direct sunlight, moisture, chemicals, and external
loads or impacts. Do not store where the equipment may be exposed to moist air, particularly where dissimilar
metals are stored together.
WARRANTY & REPAIRS
If your CMC product has a defect due to workmanship or materials, please contact CMC Customer Support at
info@cmcpro.com for warranty information and service.
CMC's warranty does not cover damages caused by improper care, improper use, alterations and
modifications, accidental damage or the natural breakdown of material over extended use and time.
The equipment should not be modified in any way or altered to allow attachment of additional parts without the
manufacturer's written recommendation. If original components are modified or removed from the product, its
safety aspects may be restricted.
All repair work shall be performed by the manufacturer. All other work or modifications void the warranty and
releases CMC from all liability and responsibility as the manufacturer.

SAMPLE INSPECTION AND MAINTENANCE LOG

The following sample log provides an example of the records that can be maintained by the purchaser or user.
EQUIPMENT INSPECTION AND MAINTENANCE LOG
Item______________#______ Date in Service________
Brand/Model_________________ Strength___________
Date How Used or Comments
Maintained
Find the latest version of this manual at cmcpro.com.
CMC Rescue, Inc.
6740 Cortona Drive
Goleta, CA 93117, USA
805-562-9120 / 800-235-5741
cmcpro.com
ISO 9001 Certified
© CMC Rescue, Inc. All rights reserved
CMC and are registered marks of CMC Rescue Inc.
CMC Control No.: 300880-01IN01_Rev00
Name
3D™

WARNINGS

Activities involving the use of this device are potentially dangerous. You
are responsible for your own actions and decisions. Before using this
device, you must:
• Read and understand these user instructions, labels, and warnings.
• Familiarize yourself with its capabilities and limitations.
• Obtain specific training in its proper use.
• Understand and accept the risks involved.
FAILURE TO HEED ANY OF THESE WARNINGS MAY RESULT IN SEVERE
INJURY OR DEATH.
MEETS THE DESCENT CONTROL DEVICE REQUIREMENTS
OF NFPA 1983, INCORPORATED IN THE 2022 EDITION OF
NFPA 2500.
300880-01, CMC 3D
• RATED FOR TECHNICAL USE (T) Ø 9.5 MM - 13 MM
• RATED FOR GENERAL USE (G) Ø 11 MM - 13 MM
THIS DESCENT CONTROL DEVICE HAS PASSED THE
MANNER OF FUNCTION AND HOLDING LOAD TESTS
USING THE FOLLOWING ROPE:
• TEUFELBERGER FIBER ROPE CORP , KMIII,
CMC PART# K05120, 9.5 MM
• TEUFELBERGER FIBER ROPE CORP , KMIII,
CMC PART# K05140, 11 MM
• TEUFELBERGER FIBER ROPE CORP , KMIII,
CMC PART# K05160, 13 MM
(KMIII USED FOR CERTIFICATION. FOR MORE INFORMATION
ON DEVICE PERFORMANCE WITH OTHER LIFE SAFETY
ROPES, PLEASE CONTACT CMC)
