2 - PRODUCT OVERVIEW

2.1 - Product description

Irreversible electromechanical gearmotor for sliding gates operating at 24 Vdc and 230 Vac. (Fig.1)

2.2 - Model and technical characteristics

CODE DESCRIPTION
SC162 230 Vac gear motor with mechanical limit switches, gate maximum weight 1600 kg
TECHNICAL DATA
MODEL
Speed*
Torque
Working cycle
Control unit
Power
Motor consumption
Consumption power
Capacitor
Thermoprotection
Protection degree
Dimension (L - P- H)
Weight
Working temperature
Max gate weight
Sound emission level

3 - PRELIMINARY CHECKS

Before installing this product, verify and check the following steps:
- Check that the gate or door are suitable for automation
- The weight and size of the gate or door must be within the
maximum permissible operating limits specified in Fig. 2
- Check the presence and strength of the security mechanical
stops of the gate or door
- Check that the mounting area of the product is not subject to
flooding
- Conditions of high acidity or salinity or proximity to heat sources
could cause malfunction of the product
- Extreme weather conditions (for example the presence of snow,
ice, high temperature range, high temperatures) may increase the
friction and therefore the force required for the handling and initial
starting point may be higher than under normal conditions.
- Check that the manual operation of gate or door is smooth and
friction-free and there is no risk of derailment of the same
- Check that the gate or door are in equilibrium and stationary if
left in any position
12
SC162
cm/s 16
Nm 40
% 30
CT102B
Vac (Vdc) 230
A 3
W 700
µF 20
°C 150
IP 44
mm 320 - 184 - 260
Kg 14,5
°C -20 +55
Kg 1600
dB(A) ≤ 70
- Check that the power line to supply the product is equipped with
proper grounding safety and protected by a magnetothermal and
differential security device
- Provide the power system with a disconnecting device with a
gap of contacts enabling full disconnection under the conditions
dictated by the overvoltage category III.
- Ensure that all materials used for the installation comply with
current regulations
